v
User-defined
impact
characters
v
Logos
v
Predefined
messages
v
User
storage
This
allows
greater
flexibility
in
allocating
memory
because
you
can
allocate
additional
memory
for
one
function
that
has
not
been
used
by
another
function.
There
are
twenty-two
64
KB
sectors,
for
a
total
of
1.4
MB
of
flash
memory
available
for
allocation.
The
MCT
value
represents
the
number
of
64
KB
sectors
assigned
to
the
respective
function.
The
amount
of
memory
allocated
to
each
function
is
specified
by
the
value
stored
in
its
respective
MCT
location.
For
information
about
adjusting
these
values,
see
“Extended
Microcode
tolerance
(MCT)
information
-
loading
(Model
TI8
only)”
on
page
122.
The
user-defined
thermal
characters
and
user-defined
impact
characters
are
limited
to
one
64
KB
sector
each.
To
change
the
memory
allocation
for
any
function,
all
memory
partitions
must
be
erased.
If
memory
is
not
erased,
an
MCT
write
error
status
is
returned.
After
the
MCT
values
are
written,
the
new
ones
take
effect
only
after
a
reset.
The
new
memory
allocations
begin
with
the
lowest
MCT
address
and
increment
up.
Memory
is
allocated
until
all
requests
are
satisfied
or
until
all
memory
has
been
used.
Table
12.
Memory
allocation
for
Model
TI8
functions
Function
Default
memory
allocation
MCT
location
User-defined
impact
characters
64
KB
X'A0'
User-defined
thermal
characters
64
KB
X'A1'
Logos
64
KB
X'A2'
Predefined
messages
64
KB
X'A3'
User
memory
128
KB
X'A4'
Scan
storage
1
MB
X'A5'
Download
graphics
(logo)
Commands
RS-232
Syntax:
GS
*
logo#
n1
n2
data
or
X'1D;2A;logo#;n1;n2;data'
where:
logo#
The
logo
number
being
stored.
v
range
=
1
to
40
for
all
models
except
TI8
v
range
=
1
to
255
for
Model
TI8
n1
One-eighth
the
number
of
dots
in
the
horizontal
direction
(width
=
8
×
n1).
range
=
1
to
72
for
a
thermal
logo.
range
=
1
to
59
for
an
impact
logo.
n2
One-eighth
the
number
of
dots
in
the
vertical
direction
(height
=
8
×
n2).
August
24,
2004
112
SureMark
Printers
User’s
Guide
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
||
|
|
||
|||
|||
|||
|||
|
|
||
|
|
