6. The scanner should be recalibrated after it has been cleaned. See “Document
scanner calibration (Model TI8).”
Document scanner calibration (Model TI8)
The printer must have power ON. Use a clean sheet of white copier paper (not
recycled paper) as the calibration target. Fold the paper in half. (Optional: cut paper
to 4.25 ″ wide.)
1. Always begin by making sure the scanner window is clean.
2. Put paper in the CR station (paper will be used for printing in later step).
3. Insert the target paper into the document insert station as you would insert a
check. The folded edge should be up (or inserted first) and the right edge
should be against the right side of the paper path. Press the DI button to
automatically advance the paper to the ready position.
4. Enter offline mode by doing the following:
a. Open the CR cover and the DI cover.
b. Press and hold both buttons until the LED flashes rapidly.
c. Close the DI cover.
d. Close the CR cover.
5.
Follow the directions that are printed in the CR station to perform the calibration.
6. Remove the target paper when complete.
7. Power the printer OFF and then ON for the changes to take effect.
Scanner
Surface
Registration Plate
Print Head
Ribbon Access Cover
Figure 31. Scanner and print head location, Model TI8
August 24, 2004
Chapter 4. Operation (Models TI1, TI2, TI3, TI4, TI8, TG3, and TG4) 59
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
