Position (listed in IOA
assignment order)
Possible failing
component DSA (BBBBCcbb) Unit address
MB1 Service processor 0001-70-00 FFFFFFFF
C07 Communication/workstation
IOA
0001-10-00 E1FFFFFF
C01 Storage IOA 0001-10-00 2FFFFFFF
C06 IOP 0001-13-00 FFFFFFFF
C06 Storage IOA 0001-10-00 3FFFFFFF
C06 Communication/workstation
IOA
0001-10-00 E3FFFFFF
C05 IOP 0001-14-00 FFFFFFFF
C05 Storage IOA The IOA has the same DSA
as the first IOP found in the
following list: C06, MB1.
4FFFFFFF
C05 Communication/workstation
IOA
The IOA has the same DSA
as the first IOP found in the
following list: C06, MB1.
E4FFFFFF
C04 (IXS capable position) IOP 0001-15-00 FFFFFFFF
C04 (IXS capable position) Storage IOA The IOA has the same DSA
as the first IOP found in the
following list: C05, C06,
MB1.
5FFFFFFF
C04 (IXS capable position) Communication/workstation
IOA
The IOA has the same DSA
as the first IOP found in the
following list: C05, C06,
MB1.
E5FFFFFF
C03 IOP 0001-16-00 FFFFFFFF
C03 Storage IOA The IOA has the same DSA
as the first IOP found in the
following list: C04, C05,
C06, MB1.
6FFFFFFF
C03 Communication/workstation
IOA
The IOA has the same DSA
as the first IOP found in the
following list: C04, C05,
C06, MB1.
E6FFFFFF
C03 IXS attached IOA The IOA has the same DSA
as the first IOP found in the
following list: C04, C05,
C06, MB1.
E506FFFF
C02 Storage IOA The IOA has the same DSA
as the first IOP found in the
following list: C03, C04,
C05, C06, MB1.
7FFFFFFF
C02 Communication/workstation
IOA
The IOA has the same DSA
as the first IOP found in the
following list: C03, C04,
C05, C06, MB1.
E7FFFFFF
C02 IXS attached IOA The IOA has the same DSA
as the first IOP found in the
following list: C03, C04,
C05, C06, MB1.
E507FFFF
Analyze hardware problems 323
