* NP: (Non-Procurable) in the Units column indicates that the part is non-procurable and that the
individual parts or the next higher assembly should be ordered.
* NR: (Not Recommended) in the Units column indicates that the part is procurable but not
recommended for field replacement and that the next higher assembly should be ordered.
* R: (Restricted) in the Units column indicates that the part has a restricted availability.
* INDENTURE: The indenture is marked by a series of dots preceding the parts description. The
indenture indicates the relationship of a part to the next higher assembly. For example:
Indenture
Relationship of Parts
(No dot)
MAIN ASSEMBLY
(One dot)
* Detail parts of a main assembly
(One dot)
* Sub assembly of the main assembly
(Two dot)
* * Detail part of a one-dot sub assembly
(Two dot)
* * Sub assembly of a one-dot sub assembly
(Three dot)
* * * Detail part of a two-dot sub assembly
Assembly
index Part number
Units
Description
3-
2512667
2513714
1 1
Cover assembly, rear, red cover assembly, rear, white for next higher
assembly, see assembly 1-2
-1 5373637 1 * Seal, top
-2 5356429 2 * Clip, retaining
-3 1847630 1 * Finger stock assembly
-4 1847602 NR * * Channel, finger stock
-5 5373639 AR * Seal, bottom
-6 5356429 2 * Clip, retaining
-7 NP * Cover, rear, without paint
-8 0416629 R * Screw, panel
Part assemblies - Models 270, 800, and 810
For use by authorized service providers.
Cover assembly
Final assembly
Control panel
Cover assembly - Models 270, 800, and 810 System Unit Expansion
366 Hardware (Remove and Replace; Part Locations and Listings)
