5. If you are instructed to return the feature key, follow all packaging instructions,
and use any packaging materials for shipping that are supplied to you.
Installing an optional ServeRAID adapter advanced feature key
The following procedure is for a Tier 1 customer replaceable unit (CRU).
Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1 CRU at
your request, you will be charged for the installation. Service agreements can be
purchased so that you can ask IBM to replace these units.
Note: Before running a procedure, refer to “Removing a file module to perform a
maintenance action” on page 51.
1. To help you work safely with Storwize V7000 Unified file modules, read the
safety information in “Safety” on page xi, “Safety statements” on page xiii, and
“Installation guidelines” on page 54.
2. Turn off the server and peripheral devices and disconnect the power cords.
3. Remove the cover, as described in “Removing the cover” on page 83.
4. Align the feature key with the connector on the ServeRAID adapter and push it
into the connector until it is firmly seated. See Figure 30 on page 123 and
Figure 31 on page 124.
ServeRAID-M5014
adapter
ServeRAID M5000
advanced feature key
sonas220
Figure 29. ServeRAID M5000 advanced feature key and M5014 adapter
122 Storwize V7000 Unified: Problem Determination Guide Version
