11
MENU SCREEN
4
4
■
Selecting the item
Follow the procedures described below to select a
Menu screen.
Example: T
urning ON the V
oice Squelch function.
1.
Open “V
oice SQL.”
[MENU] > Radio Settings >
V
oice SQL
2.
Select “On.”
•
Returns to the Radio Settings screen.
3.
Push [MENU], or
to return to the M
ain
screen.
+
Push
Rotate
+
Push
Rotate
+
Push
Rotate
18
