Icom ID-5100A Service Manual

5-6
ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE
SENSITIVITY • Connect a Standard Signal Generator to the antenna connector.
118.020 MHz (Band A)
[LT1]
1 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
Touch [ENT].
(Automatic
adjustment)
(Band B)
[LT1]
2
146.020 MHz (Band A)
[MT1]
3 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[MT1]
4
173.980 MHz (Band A)
[HT1]
5 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[HT1]
6
375.020 MHz (Band A)
[LT4]
7 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[LT4]
8
420.020 MHz (Band A)
[MT4]
9 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[MT4]
10
449.980 MHz (Band A)
[HT4]
11 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[HT4]
12
450.020 MHz (Band A)
[LT5]
13 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[LT5]
14
500.020 MHz (Band A)
[MT5]
15 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[MT5]
16
549.980 MHz (Band A)
[HT5]
17 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level: 0 dBµ (–107 dBm)
(Band B)
[HT5]
18
M RECEIVE SENSITIVITY ADJUSTMENT
1) Select the adjustment item by rotating Band A [DIAL].
2) Set or modify the adjustment value as specifi ed, by rotating Band B [DIAL].
3) Touch [ENT] to store the value.
5-4 RECEIVE ADJUSTMENTS
