Icom ID-5100A Service Manual

5-7
ADJUSTMENT ITEM
ADJUSTMENT
CONDITIONS
OPERATION VALUE
S-METER
127.020 MHz
• Connect a Standard Signal Generator to the antenna connector.
Band A (AM) [S11] 1 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level:
–6 dBµ (–113 dBm)
Touch [ENT].
(Automatic
adjustment)
Band B (AM) [S11] 2
Band A (AM) [S31] 3 Set the SSG as:
Level: 0 dBµ (–107 dBm)
Band B (AM) [S31] 4
Band A (AM) [SF1] 5 Set the SSG as:
Level:
+10 dBµ (–97 dBm)
Band B (AM) [SF1] 6
145.020 MHz Band A (FM) [S12] 7 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level:
–6 dBµ (–113 dBm)
Band B (FM) [S12] 8
Band A (FM) [S32] 9 Set the SSG as:
Level: 0 dBµ (–107 dBm)
Band B (FM) [S32] 10
Band A (FM) [SF2] 11 Set the SSG as:
Level:
+10 dBµ (–97 dBm)
Band B (FM) [SF2] 12
387.020 MHz Band A (FM) [S13] 13 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level:
–6 dBµ (–113 dBm)
Band B (FM) [S13] 14
Band A (FM) [S33] 15 Set the SSG as:
Level: 0 dBµ (–107 dBm)
Band B (FM) [S33] 16
Band A (FM) [SF3] 17 Set the SSG as:
Level:
+10 dBµ (–97 dBm)
Band B (FM) [SF3] 18
435.020 MHz*
445.020 MHz**
Band A (FM) [S14] 19 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level:
–6 dBµ (–113 dBm)
Band B (FM) [S14] 20
Band A (FM) [S34] 21 Set the SSG as:
Level: 0 dBµ (–107 dBm)
Band B (FM) [S34] 22
Band A (FM) [SF4] 23 Set the SSG as:
Level:
+10 dBµ (–97 dBm)
Band B (FM) [SF4] 24
500.020 MHz Band A (FM) [S15] 25 Set the SSG as:
Frequency: (Displayed)
Modulation: None
Level:
–6 dBµ (–113 dBm)
Band B (FM) [S15] 26
Band A (FM) [S35] 27 Set the SSG as:
Level: 0 dBµ (–107 dBm)
Band B (FM) [S35] 28
Band A (FM) [SF5] 29 Set the SSG as:
Level:
+10 dBµ (–97 dBm)
Band B (FM) [SF5] 30
M S-METER ADJUSTMENT
1) Select the adjustment item by rotating Band A [DIAL].
2) Confi gure the SSG setting as specifi ed.
3) Touch [ENT] to automatically adjust and store the value.
