Icom ID-5100A Service Manual

1-1
SECTION 1
.
SPECIFICATIONS
General
■
• Frequency coverage:
EUR
RX 118–174 MHz*
1
, 375–550 MHz*
2
TX 144–146 MHz, 430–440 MHz
ITR
RX 118–136.99166 MHz*
3
, 144–146 MHz, 430–434 MHz, 435–438 MHz
TX 144–146 MHz, 430–434 MHz, 435–438 MHz
TPE
RX 144–146 MHz, 430–432 MHz
TX 144–146 MHz, 430–432 MHz
USA
RX 118–174 MHz*
4
, 375–550 MHz*
5
TX 144–148 MHz, 430–450 MHz*
5
KOR
RX 144–146 MHz, 430–440 MHz
TX 144–146 MHz, 430–440 MHz
EXP
RX 118–174 MHz*
4
, 375–550 MHz*
2
TX 137–174 MHz*
4
, 400–470 MHz*
2
*
1
Guaranteed only 144–146 MHz, *
2
Guaranteed only 430–440 MHz, *
3
Not guaranteed,
*
4
Guaranteed only 144–148 MHz, *
5
Guaranteed only 440–450 MHz
• Mode: F2D/F3E (FM/FM-N), F7W (DV), A3E (AM/AM-N) RX only
• Number of memory channels: 1000 channels
• Number of program scan channels: 25 channels
(2 edge frequencies in each channel)
• Number of call channels: 4 channels (2 channels × 2 bands)
• Antenna connector: SO-239
• Antenna impedance: 50 ø
• Usable temperature range: –10˚C to +60˚C; +14˚F to +140˚F
• Frequency stability: ±2.5 ppm (–10˚C to +60˚C; +14˚F to +140˚F)
•
Digital transmission speed : 4.8 kbps
• Voice coding speed: 2.4 kbps
• Frequency resolution: 5 kHz, 6.25 kHz, 8.33 kHz, 10 kHz, 12.5 kHz, 15 kHz, 20 kHz, 25 kHz, 30 kHz, 50 kHz
(The 8.33 kHz step is selectable only when the VHF air band is selected.)
• Power supply: 13.8 V DC ±15% (negative ground)
• Current drain:
Transmit
Maximum current drain:  10.5 A (TPE version)
 13.0 A (Other versions)
Receive
Standby:  1.2 A
Maximum audio:  1.8 A
• Dimensions (projections not included):
Main unit: 150(W)  40(H)  172.6(D) mm; 5.9(W)  1.6(H)  6.8(D) inch
Controller:
182.2(W)  24.8(H)  81.5(D) mm; 7.2(W)  1.0(H)  3.2(D) inch
• Weight (approximately):
Main unit: 1.3 kg; 2.9 lb
Controller: 260 g; 9.2 oz

Icom ID-5100A Specifications

General

Brand	Icom
Model	ID-5100A
Category	Transceiver
Language	English
