Inovance MD380 Series User Manual

Description of Function Codes
MD380 User Manual
- 140 -
Chapter 6 Description of Function Codes
Group F0: Basic Parameters
Function Code Parameter Name Setting Range Default
F0-00 G/P type display
1: G type (constant torque load)
2: P type (variable torque load e.g. fan
and pump)
Model
dependent
7KLVSDUDPHWHULVXVHGWRGLVSOD\WKHGHOLYHUHGPRGHODQGFDQQRWEHPRGL¿HG
 $SSOLFDEOHWRFRQVWDQWWRUTXHORDGZLWKUDWHGSDUDPHWHUVVSHFL¿HG
 $SSOLFDEOHWRYDULDEOHWRUTXHORDGIDQDQGSXPSZLWKUDWHGSDUDPHWHUVVSHFL¿HG
Function Code Parameter Name Setting Range Default
F0-01
Motor 1 control
mode
0: SVC
1: CLVC
2: V/F control
0
 0: SVC
It indicates open-loop vector control, and is applicable to high-performance control
applications such as machine tool, centrifuge, wire drawing machine and injection
PRXOGLQJPDFKLQH2QH$&GULYHFDQRSHUDWHRQO\RQHPRWRU
 1: CLVC
It indicates closed-loop vector control and is applicable to high-accuracy speed control
or torque control applications such as high-speed paper making machine, crane and
HOHYDWRU2QH$&GULYHFDQRSHUDWHRQO\RQHPRWRU$QHQFRGHUPXVWEHLQVWDOOHGDWWKH
motor side, and a PG card matching the encoder must be installed at the AC drive side.
 2: V/F control
It is applicable to applications with low load requirements or applications where one AC
drive operates multiple motors, such as fan and pump.
Note
If vector control is used, motor auto-tuning must be performed because the advantages of vector
control can only be utilized after correct motor parameters are obtained. Better performance can
be achieved by adjusting speed regulator parameters in group F2 (or group A2 for motor 2).
