Chapter 8 Selection and Dimensions
(OHFWULFDO6SHFL¿FDWLRQVRIWKH0'
Table 8-1 Models and technical data of the MD380
Model
Power
Capacity
(kVA)
Input
Current (A)
2XWSXW
Current
(A)
Adaptable
Motor
N:+3
Thermal Power
Consumption
N:
Single-phase 220 V, 50/60 Hz
MD380S0.4GB 1 5.4 2.3 0.4 0.5 0.016
MD380S0.7GB 1.5 8.2 4 0.75 1 0.030
MD380S1.5GB 3 14 7 1.5 2 0.055
MD380S2.2GB 4 23 9.6 2.2 3 0.072
Three-phase 220 V, 50/60 Hz
MD380-2T0.4GB 1.5 3.4 2.1 0.4 0.5 0.016
MD380-2T0.75GB 3 5 3.8 0.75 1 0.030
MD380-2T1.5GB 4 5.8 5.1 1.5 2 0.055
MD380-2T2.2GB 5.9 10.5 9 2.2 3 0.072
MD380-2T3.7GB 8.9 14.6 13 3.7 5 0.132
MD380-2T5.5GB 17 26 25 5.5 7.5 0.214
MD380-2T7.5GB 21 35 32 7.5 10 0.288
MD380-2T11G 30 46.5 45 11 15 0.489
MD380-2T15G 40 62 60 15 20 0.608
MD380-2T18.5G 57 76 75 18.5 25 0.716
MD380-2T22G 69 92 91 22 30 0.887
MD380-2T30G 85 113 112 30 40 1.11
MD380-2T37G 114 157 150 37
50 1.32
MD380-2T45G 134 180 176 45 60 1.66
MD380-2T55G 160 214 210 55 75 1.98
MD380-2T75G 231 307 304 75 100 2.02
Three-phase 380 V, 50/60 Hz
MD380T0.7GB 1.5 3.4 2.1 0.75 1 0.027
MD380T1.5GB 3 5 3.8 1.5 2 0.050
MD380T2.2GB 4 5.8 5.1 2.2 3 0.066
MD380T3.7GB 5.9 10.5 9 3.7 5 0.120
MD380T5.5GB
MD380T5.5PB
8.9 14.6 13 5.5 7.5 0.195
