Integra DHC-80.3 User Manual

104
En
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
THD+N (Total Harmonic Distortion+Noise)
0.05% (20 Hz - 20 kHz, half power)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1V/470 Ω (PRE OUT)
Maximum RCA Output Level and Impedance
5.5 V/470 Ω (PRE OUT)
Rated XLR Output Level and Impedance
2 V/470 Ω (PRE OUT)
Maximum XLR Output Level and Impedance
11.0 V/470 Ω (PRE OUT)
Phono Overload 70 mV (MM 1 kHz 0.5%)
Frequency Response 5 Hz - 100 kHz/+1 dB, -3 dB (Direct mode)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component and S-Video Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, -3 dB
FM Tuning Frequency Range
(North American)
87.5 MHz - 107.9 MHz
(Others)
87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply (North American)
AC 120 V, 60 Hz
(Others)
AC 220 - 240 V, 50/60 Hz
Power Consumption (North American) 1.2 A
(Others) 110 W
No-sound Power Consumption
(North American) 1.2 A
(Others) 110 W
Stand-by Power Consumption
(North American) 0.2 W
(Others) 0.3 W
Dimensions (W × H × D)
435 mm × 198.5 mm × 445 mm
17-1/8" × 7-13/16" × 17-1/2"
Weight 13.5 kg (29.8 lbs.)
Input IN 1, IN 2, IN 3, IN 4, IN 5, IN 6, IN 7,
AUX (Front)
Output OUT MAIN, OUT SUB
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel (OUT MAIN),
DeepColor, x.v.Color, LipSync,
CEC (RIHD)
Component IN 1, IN 2, IN 3
S-Video BD/DVD, VCR/DVR, CBL/SAT, GAME
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,
AUX
Analog RGB PC IN
Component MONITOR OUT, ZONE2 OUT
S-Video MONITOR OUT, VCR/DVR (REC OUT)
Composite MONITOR OUT, VCR/DVR (REC OUT),
ZONE2 OUT
Digital Optical: 3 (Rear), 1 (Front)
Coaxial: 3
Analog BD/DVD, MULTI CH, VCR/DVR,
CBL/SAT, GAME, PC, TV/CD, PHONO,
AUX
Multichannel Inputs 7.1
Balance Inputs 2 (L/R)
Analog VCR/DVR, PRE OUT, ZONE2 PRE/LINE
OUT, ZONE3 PRE/LINE OUT
Balance Pre Outputs FL, FR, C, SL, SR, SBL, SBR,
FHL/FWL, FHR/FWR, SW1, SW2
Analog Multichannel Pre Outputs
9
Subwoofer Pre Outputs
2
Phones 1 (6.3 ø)
Setup Mic 1
RS232 1
Universal Port 1
RI 1
USB 1 (Front)/1 (Rear)
Ethernet 1
IR Input 2
IR Output 1
12 V Trigger Out 3
