Land Listing and Signal Descriptions
44 Datasheet
FC32 H15 Power/Other
FC33 H16 Power/Other
FC34 J17 Power/Other
FC35 H4 Power/Other
FC36 AD3 Power/Other
FC37 AB3 Power/Other
FC39 AA2 Power/Other
FC4 T2 Power/Other
FC40 AM6 Power/Other
FC8 AK6 Power/Other
FERR#/PBE# R3 Asynch CMOS Output
GTLREF0 H1 Power/Other Input
GTLREF1 H2 Power/Other Input
GTLREF2 G10 Power/Other Input
GTLREF3 F2 Power/Other Input
HIT# D4 Common Clock Input/Output
HITM# E4 Common Clock Input/Output
IERR# AB2 Asynch CMOS Output
IGNNE# N2 Asynch CMOS Input
INIT# P3 Asynch CMOS Input
ITP_CLK0 AK3 TAP Input
ITP_CLK1 AJ3 TAP Input
LINT0 K1 Asynch CMOS Input
LINT1 L1 Asynch CMOS Input
LOCK# C3 Common Clock Input/Output
MSID0 W1 Power/Other Output
MSID1 V1 Power/Other Output
PECI G5 Power/Other Input/Output
PROCHOT# AL2 Asynch CMOS Input/Output
PWRGOOD N1 Power/Other Input
REQ0# K4 Source Synch Input/Output
REQ1# J5 Source Synch Input/Output
REQ2# M6 Source Synch Input/Output
REQ3# K6 Source Synch Input/Output
REQ4# J6 Source Synch Input/Output
RESERVED A20
RESERVED AC4
RESERVED AE4
RESERVED AE6
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
RESERVED AH2
RESERVED D1
RESERVED D14
RESERVED D16
RESERVED E23
RESERVED E6
RESERVED E7
RESERVED F23
RESERVED F29
RESERVED G6
RESERVED N4
RESERVED N5
RESERVED P5
RESERVED V2
RESET# G23 Common Clock Input
RS0# B3 Common Clock Input
RS1# F5 Common Clock Input
RS2# A3 Common Clock Input
SKTOCC# AE8 Power/Other Output
SMI# P2 Asynch CMOS Input
STPCLK# M3 Asynch CMOS Input
TCK AE1 TAP Input
TDI AD1 TAP Input
TDI_M W2 Power/Other Input
TDO AF1 TAP Output
TDO_M U1 TAP Output
TESTHI0 F26 Power/Other Input
TESTHI1 W3 Power/Other Input
TESTHI10 H5 Power/Other Input
TESTHI11 P1 Power/Other Input
TESTHI13 L2 Power/Other Input
TESTHI2 F25 Power/Other Input
TESTHI3 G25 Power/Other Input
TESTHI4 G27 Power/Other Input
TESTHI5 G26 Power/Other Input
TESTHI6 G24 Power/Other Input
TESTHI7 F24 Power/Other Input
THERMTRIP# M2 Asynch CMOS Output
TMS AC1 TAP Input
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
