Land Listing and Signal Descriptions
52 Datasheet
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
A2 VSS Power/Other
A3 RS2# Common Clock Input
A4 D02# Source Synch Input/Output
A5 D04# Source Synch Input/Output
A6 VSS Power/Other
A7 D07# Source Synch Input/Output
A8 DBI0# Source Synch Input/Output
A9 VSS Power/Other
A10 D08# Source Synch Input/Output
A11 D09# Source Synch Input/Output
A12 VSS Power/Other
A13 COMP0 Power/Other Input
A14 D50# Source Synch Input/Output
A15 VSS Power/Other
A16 DSTBN3# Source Synch Input/Output
A17 D56# Source Synch Input/Output
A18 VSS Power/Other
A19 D61# Source Synch Input/Output
A20 RESERVED
A21 VSS Power/Other
A22 D62# Source Synch Input/Output
A23 VCCA Power/Other
A24 FC23 Power/Other
A25 VTT Power/Other
A26 VTT Power/Other
A27 VTT Power/Other
A28 VTT Power/Other
A29 VTT Power/Other
A30 VTT Power/Other
B1 VSS Power/Other
B2 DBSY# Common Clock Input/Output
B3 RS0# Common Clock Input
B4 D00# Source Synch Input/Output
B5 VSS Power/Other
B6 D05# Source Synch Input/Output
B7 D06# Source Synch Input/Output
B8 VSS Power/Other
B9 DSTBP0# Source Synch Input/Output
B10 D10# Source Synch Input/Output
B11 VSS Power/Other
B12 D13# Source Synch Input/Output
B13 COMP8 Power/Other Input
B14 VSS Power/Other
B15 D53# Source Synch Input/Output
B16 D55# Source Synch Input/Output
B17 VSS Power/Other
B18 D57# Source Synch Input/Output
B19 D60# Source Synch Input/Output
B20 VSS Power/Other
B21 D59# Source Synch Input/Output
B22 D63# Source Synch Input/Output
B23 VSSA Power/Other
B24 VSS Power/Other
B25 VTT Power/Other
B26 VTT Power/Other
B27 VTT Power/Other
B28 VTT Power/Other
B29 VTT Power/Other
B30 VTT Power/Other
C1 DRDY# Common Clock Input/Output
C2 BNR# Common Clock Input/Output
C3 LOCK# Common Clock Input/Output
C4 VSS Power/Other
C5 D01# Source Synch Input/Output
C6 D03# Source Synch Input/Output
C7 VSS Power/Other
C8 DSTBN0# Source Synch Input/Output
C9 BPMb1#
Common
Clock
Input/Output
C10 VSS Power/Other
C11 D11# Source Synch Input/Output
C12 D14# Source Synch Input/Output
C13 VSS Power/Other
C14 D52# Source Synch Input/Output
C15 D51# Source Synch Input/Output
C16 VSS Power/Other
C17 DSTBP3# Source Synch Input/Output
C18 D54# Source Synch Input/Output
C19 VSS Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
