Interacoustics Eclipse User Manual

D-0120578-C – 2019/11
Eclipse – Instructions for Use - US
Page 130
10.4 Technical specifications DPOAE
Medical CE-mark:
The Medical CE mark indicates that Interacoustics AS meets the requirements of Annex II of
the Medical Device Directive 93/42/EEC. Approval of the quality system is made by TÜV –
identification no 0123.
Standards
Test Signal:
IEC 60645-1:2012 /ANSI S3.6
OAE
DPOAE IEC 60645-6:2009, Type 2 Otoacoustic emissions
Stimulus:
Frequency Range:
500-10000 Hz
Frequency Step:
25 Hz
Level:
30 to 70 dB SPL
Level Step:
1 dB SPL
Transducer:
Dedicated DPOAE/TEOAE probe
Recording:
Analysis time:
minimum 2 sec to unlimited test time
A/D Resolution:
16 bit, 3.7 Hz resolution
Sampling frequency
30 kHz
Artifact Reject System:
-30 to +30 dB SPL or off. Applicable during testing
Stimulus Tolerance:
Adjustable between 1 and 10 dB
SNR Criteria:
Adjustable between 3 and 25 dB
Probe check window
256 points frequency response of the ear canal due to a click
stimulus presented with a rate of 100 Hz at 80 dB SPL
DP-Response window
4096 points frequency response
Display gain:
General Display gain:
Applicable during testing
OAE Probe Specifications:
Probe:
Application:
DPOAE measurements
Dimensions:
(W x D x H) 12 x 26 x 11 mm (exc. Eclipse)
Weight:
3 g (exc. Cable, exc. Eclipse)
39 g (incl. cable, exc. Eclipse)
Cable:
Length:
2980 mm cable
Note ! The OAE probe is dedicated to one Eclipse only! Calibration is stored on the Eclipse. Replacing
the OAE transducer will require new calibration of the transducer connected to the Eclipse.
DPOAE Calibration:
Probe stimuli L1 and L2 are calibrated individually in SPL values using the IEC 711 ear simulator coupler
made in accordance to IEC 60318-4.
The DPOAE module uses an improved method of stimuli level control, which more accurately delivers the
specified intensity in the full range of ear canals, from infants to adults. The applicability of the IEC 60645-
6 standard is currently limited to adult ears. Therefore, in order to better serve a market with a product
that provides more accurate stimulus levels to a wide range of ear canal volumes (specifically infants), we
have elected to utilize a more comprehensive calibration procedure for DPOAEs that is outside the scope
of IEC 60645-6 for some protocols.
This improved method of stimulus control is enabled when the “Use Microphone compensation” checkbox
is checked. To use the IEC60645-6 calibration method, uncheck the “Use Microphone compensation” in
the Advanced tab of the protocol setup.
