Goodrive20 inverters Appendix C
134
Character
designation
Detailed instruction
A FLT:inverter filter series
B
Filter type
P:power supply filter
L:output filter
C
Voltage degree
S2: AC 1PH 220V(-15%)~240V(+10%)
04: AC 3PH 380V(-15%)~440V(+10%)
D 3 bit rated current code “016” means 16A
E
Installation type
L: Common type
H: High performance type
F
Utilization environment of the filters
A:the first envirtonment (IEC61800-3:2004) category C1 (EN 61800-3:2004)
B:the first envirtonment (IEC61800-3:2004) category C2 (EN 61800-3:2004)
C.6.5 C2 filter
Model Input filter Output filter
GD20-0R4G-S2
FLT-PS2010H-B FLT-L04006L-B
GD20-0R7G-S2
GD20-1R5G-S2
FLT-PS2025L-B FLT-L04016L-B
GD20-2R2G-S2
GD20-0R4G-2
FLT-P04006L-B FLT-L04006L-B
GD20-0R7G-2
GD20-1R5G-2
FLT-P04016L-B FLT-L04016L-B
GD20-2R2G-2
GD20-004G-2
FLT-P04032L-B FLT-L04032L-B
GD20-5R5G-2
GD20-7R5G-2 FLT-P04045L-B FLT-L04045L-B
GD20-0R7G-4
FLT-P04006L-B FLT-L04006L-B GD20-1R5G-4
GD20-2R2G-4
GD20-004G-4
FLT-P04016L-B FLT-L04016L-B
GD20-5R5G-4
GD20-7R5G-4
FLT-P04032L-B FLT-L04032L-B
GD20-011G-4
GD20-015G-4
FLT-P04045L-B FLT-L04045L-B
GD20-018G-4
