Goodrive20 inverters Function Parameters
64
Function
code
Name Detailed instruction of parameters
Default
value
Modify
faults
P07.56
Output
terminals state
at previous 2
faults
0 ●
P08 Group Enhanced functions
P08.00
ACC time 2
Refer to P00.11 and P00.12 for detailed definition.
Goodrive20 series define four groups of ACC/DEC time
which can be selected by P5 group. The first group of
ACC/DEC time is the factory default one.
Setting range:0.0~3600.0s
Depend
on model
○
P08.01
DEC time 2
Depend
on model
○
P08.02
ACC time 3
Depend
on model
○
P08.03
DEC time 3
Depend
on model
○
P08.04
ACC time 4
Depend
on model
○
P08.05
DEC time 4
Depend
on model
○
P08.06
Jogging
running
frequency
This parameter is used to define the reference frequency
during jogging.
Setting range: 0.00Hz ~P00.03(the Max. frequency)
5.00Hz
○
P08.07
Jogging
running ACC
time
The jogging ACC time means the time needed if the inverter
runs from 0Hz to the Max. Frequency.
The jogging DEC time means the time needed if the inverter
goes from the Max. Frequency (P00.03) to 0Hz.
Setting range:0.0~3600.0s
Depend
on model
○
P08.08
Jogging
running DEC
time
Depend
on model
○
P08.09
Jumping
frequency 1
When the set frequency is in the range of jumping
frequency, the inverter will run at the edge of the jumping
frequency.
The inverter can avoid the mechanical resonance point by
setting the jumping frequency. The inverter can set three
jumping frequency. But this function will be invalid if all
jumping points are 0.
0.00Hz
○
P08.10
jumping
frequency
range 1
0.00Hz
○
P08.11
Jumping
frequency 2
0.00Hz
○
P08.12
Jumping
frequency
range 2
0.00Hz
○
P08.13
Jumping
frequency 3
0.00Hz
○
