Quick Reference
1.3 Keyboard Introduction
The keyboard introduction of IT-M3140 series power supplies is shown as
follows.
Keys Description
[On/Off] Turns the instrument output on or off. When lit, indicates that the
output is enabled or on.
[V-set] Sets the output voltage value.
[I-set] Sets the output current value.
[Save] Saves the present settings. IT-M3200 power supplies support up
to 10 saved setups.
[Recall] Returns the instrument to the specified setup.
[Esc] Returns to the previous menu level.
[Enter] Selects the menu item or confirm an operation.
Moves the cursor below the setting value or scrolls pages to view
menu items.
Composite key [Shift], combined with other keys to realize functions marked
above keys. The detailed functions are listed as follows.
Copyright © Itech Electronic Co., Ltd.
3
