jcb 19C-1E User Manual

Technical Data
Noise Emissions
Noise Emissions
General
To assist in compliance with European Directives 2000/14/EC and 2005/88/EC, the noise data values for this
type of machine have been provided on the following page(s) and may be used for the assessment of risks
to exposure from noise.
The noise data values shown only apply to CE marked machines.
For information relating to this machine when used with other JCB approved attachments, please refer to the
literature accompanying the attachments.
Table 17. Definition of terms
Term Definition Notes
LpA A-weighted sound pressure level mea-
sured at the operator's station.
Determined in accordance with the test method
defined in ISO 6396 and the dynamic test condi-
tions defined on 2000/14/EC.
LwA Equivalent A-weighted sound power level
emitted by the machine.
Guaranteed equivalent sound power (external
noise) determined in accordance with the dynamic
test conditions defined in 2000/14/EC.
Noise Data
Table 18.
Noise Uncertainty Measurement
Conditions
Rating
(1)
Noise at the op-
erator station
(LpA)
72 dB (KpA) 1 dB ISO 6396:2008
Noise emission
from the ma-
chine (LwA)
85 dB (KwA) 1 dB ISO 6395:1988
7kW continuous
(1) Net installed power.
153 9831/8250-4 153
JCB © Admin Pimteam - 23/06/2021 05:32.

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
