Attachments
Working with Attachments
Do not operate or work with attachments until the machine hydraulic oil has reached its normal working
temperature.
Notice: Some attachments may contact parts of the machine when in the fully folded position. Take extra care
to avoid damage to the machine.
List of attachments applicable for your machine. Refer to Table 8.
Table 8.
Part No. Attachments Description 19C-1e
980/B0508 150mm GP bucket (inclusive teeth) Yes
980/B0435 230mm GP bucket (inclusive teeth) Yes
980/B0436 300mm GP bucket (inclusive teeth) Yes
980/B0437 400mm GP bucket (inclusive teeth) Yes
980/B0438 460mm GP bucket (inclusive teeth) Yes
980/B0439 610mm GP bucket (inclusive teeth) Yes
980/B0521 150mm GP bucket (inclusive teeth) and pins Yes
980/B0522 230mm GP bucket (inclusive teeth) and pins Yes
980/B0523 300mm GP bucket (inclusive teeth) and pins Yes
980/B0524 400mm GP bucket (inclusive teeth) and pins Yes
980/B0525 460mm GP bucket (inclusive teeth) and pins Yes
980/B0526 610mm GP bucket (inclusive teeth) and pins Yes
980/B0501 150mm GP bucket, bolt on toeplate, and pins Yes
980/B0502 230mm GP bucket, bolt on toeplate, and pins Yes
980/B0503 300mm GP bucket, bolt on toeplate, and pins Yes
980/B0504 400mm GP bucket, bolt on toeplate, and pins Yes
980/B0505 460mm GP bucket, bolt on toeplate, and pins Yes
980/B0506 600mm GP bucket, bolt on toeplate, and pins Yes
980/B0107 760mm Ditch maintenance bucket Yes
980/B0108 1,000mm Ditch maintenance bucket Yes
980/B4000 Mechanical Quickhitch Yes
980/B5000
Mechanical Quickhitch - conversion
(1)
Yes
980/B6000 Hydraulic Quickhitch Yes
980/B3202 Earth drill - 1,500N·m Yes
980/H6662 HM100Q Yes
980/B5211 HM012T- top mount Yes
980/B0450
Quickhitch adaptor (auger)
(2)
Yes
(1) Mechanical Quickhitch is compatible with JCB supplied old buckets.
(2) Adaptor to connect earth drill to mechanical and hydraulic Quickhitch.
(3) GP is abbreviation for General Purpose.
Connecting/Disconnecting Hydraulic Hoses
WARNING Fine jets of fluid at high pressure can penetrate the skin. Keep face and hands well clear of fluid
under pressure and wear personal protective equipment. Hold a piece of cardboard close to suspected leaks
and then examine the cardboard for signs of fluid. If fluid penetrates your skin, get medical help immediately.
WARNING Hydraulic fluid at system pressure can injure you. Before connecting or removing any hydraulic
hose, residual hydraulic pressure trapped in the service hose line must be vented. Make sure the hose
service line has been vented before connecting or removing hoses. Do not start the motor with loose or
open hose connections.
Some attachments are hydraulically powered. The following procedures show how to connect and disconnect
the hydraulic hoses safely.
82 9831/8250-4 82
