Operation
Working with the Machine
132
132
981
1/9950-1
Working on Slo
pes
When working on incl
ines, position the dozer fo
r maximum
stability
. This may mean the dozer and the boom are at the
same end of the machine, especially if digging down hill,
lower the dozer sufficiently to bring the machi
ne level. If
necessary
, to prevent an instability problem, cut a level
platform for the machine to stand on.
732230-4
Fig
61.
HE Services
