Operation
Moving A Disabled Machine
144 144
9811/9950-1
Retrieval
Important: It is not recommended to tow a disabled
machine. Permanent damage to the track motors of the
disabled machine may occur if the machine is towed.
If the machine becomes disabled, the machine should be
made safe, lifted onto a transporter and moved to a
location where is can be repaired. K
Lifting a
Machine ( T 154).
In the event that towing the machine to a safe location is
unavoidable then attach wire rope or chain capable of
pulling the machine to the lower frame as shown.
K
Fig 65. ( T 144).
Important: Do not use the tow eye or tie down points (if
installed) to tow the machine, as this will cause damage to
the machine.
T033230-5
Fig 65.
