Routine Maintenance

Fluids, Lubricants and Capacities

181 181

9811/9950-1

Track Rollers (bottom) 0.08 (0.02) JCB HD90 Gear Oil API-GL-5, MIL-L-2105D

Hydraulic Tank 40 (8.8) JCB Special Hydraulic Fluid

Up to 30°C (86°F)

JCB Hydraulic Fluid 46

Over 30°C (86°F)

Slew Ring Bearings JCB MPL Grease Lithium based no 2 consistency

Slew Ring Gear Teeth JCB Slew Pinion Grease

All Other Grease JCB MPL Grease Lithium based no 2 consistency

Item Capacity

Litres (UK

Gal)

Fluid / Lubricant International Specification

HE Services

Default Chapter3
- Table of Contents3
Contents18
