Specifications
Performance Dimensions
293 293
9811/9950-1
Table 7.
8026 CTS 8025 ZTS 8030 ZTS 8035 ZTS
mm (ft-in) mm (ft-in) mm (ft-in) mm (ft-in)
A Max. digging height 4435 (14-6) 4333 (14 -2) 4453 (14-7) 4601 (15 -2)
B Max. dumping height 3088 (10 -1) 3158 (10 -4) 3205 (10-6) 3482 (11-5)
C Max. vertical digging depth 1925 (6-3) 1542 (5-1) 1741 (5-8) 2165 (7-1)
D
Max. digging depth
(1)
(1) Max. dig depth when dozer blade fully lowered.
2783 (9-0) 2832 (9-3) 3119 (10-3) 3512 (11-6)
E Max. reach (ground level) 4600 (15 -0) 4828 (15 -10) 5031 (16 -6) 5436 (17-10)
F Min. boom swing radius 1875 (6-0) 2125 (6-11) 2150 (7-0) 2492 (8-2)
G Blade cut above ground 275 (0-11) 340 (1-1) 414 (1-4) 413 (1-4)
H Blade cut below ground 435 (1-4) 398 (1-3) 622 (2-0) 629 (2-1)
