Operation
Drive Controls, Switches and Instruments
78 78
9811/9950-1
Warning Indicators
!MCAUTION
If any of the audible/visual warnings operate while the
engine is running, stop the engine as soon as it is safe
to do so and rectify the fault.
4-2-1-2
A buzzer will sound if any warning indicators 1, 2 or 3
display a machine fault. K
Instrument Panel ( T 75).
If the fault is ignored the buzzer will sound continuously for
180 seconds, after which it will sound intermittently, one
second on, two seconds off.
Set the starter key to the off position to reset all operations.
1 Charge (Fault) Indicator
Audible/Visual. Indicates Alternator operation.
Illuminates RED when a fault occurs.
2 Coolant Indicator (On)
Visual. Illuminates when the engine coolant
overheats. The light should go out when the engine
is started.
3 Engine Oil Pressure (On)
Visual. Illuminates if the engine oil pressure drops
too far. The light should go out when the engine is
started.
To Next Page
