Section J - Tracks
Technical Data
General Data
J-1 J-1
9803-9570-4
Technical Data
General Data
Tracks
Bottom Rollers
Idler Wheels
Wear Tolerances
Type Rubber
Width 180 mm (7.09 in)
Number of links 35
Link Pitch 72 mm (2.8 in)
Type Sealed for life
Quantity 2 per side
Type Sealed for life
Adjustment Manual or hydraulic
Nominal Tolerance
Wear on roller (guide width) 15 mm (0.590 in.) - 6 mm (- 0.236 in.) minimum
Wear on roller (O/D) 93 mm (3.661 in.) - 5 mm (- 0.197 in.) minimum
Wear on idler external surface (width) 48 mm (1.890 in.) - 8 mm (- 0.315 in.) minimum
Wear on idler external surface (guide width) 15 mm (0.590 in.) - 6 mm (- 0.236 in.) minimum
Wear on idler (O/D) 213 mm (8.386 in.) - 5 mm (- 0.197 in.) minimum
Driven Sprocket tip end (O/D) 254 mm (10.000 in.) - 8 mm (- 0.315 in.) minimum
Driven Sprocket tip end (width) 19 mm (0.748 in.) - 4 mm (- 0.157 in.) minimum
