jcb Dumpster HTD5 User Manual

Section E - Hydraulics
Technical Data
General Data
E-2 E-2
9803-9570-4
Relief Valve Operating Pressures
Pressures are given at normal working temperature of 50
deg C.
Filter
Rams
Dimensions
Torque Settings
bar
lbf/in
2
Main Relief Valve: at max. rev/min 150 2175
Track Motor Relief Valve Setting 150 2175
Type Cartridge
Ram
Location
Bore Rod Dia Stroke
(mm) (in) (mm) (in) (mm) (in)
Lift 45 1.78 25 0.98 387 15.2
Tip 45 1.78 25 0.98 387 15.2
Torque
Nm (lbf ft)
Piston Head
Lift 200 148
Tilt 200 148
End Cap
Lift 300 221
Tilt 300 221
