jcb Dumpster HTD5 User Manual

Section E - Hydraulics
E-1 E-1
9803-9570-4
Technical Data
General Data
Note: System Cleanliness is to be to ISO 16/13 -
K Service Procedures ( T E-13)
Loader Pump up to machine no. 1360178
Loader Pump from machine no. 1360179
Track Motors
Valve Block
Type DTL Triple Gear
Displacement
8.8 cc/rev (0.537 in
3
/rev)
Maximum flow at 3000 rev/min and 150 bar (2175 lbf/in
2
)
- Combined (all three elements) 26.5 l/min (5.83 UK gal/min, 7.0 US gal/min)
- First element 6.5 l/min (1.43 UK gal/min, 1.72 US gal/min)
- Second element 6.5 l/min (1.43 UK gal/min, 1.72 US gal/min)
- Third element 13.5 l/min (2.97 UK gal/min, 3.56 US gal/min)
Type DTL Triple Gear
Displacement
8.17 cc/rev (0.499 in
3
/rev)
Maximum flow at 3000 rev/min and 150 bar (2175 lbf/in
2
)
- Combined (all three elements) 20.8 l/min (4.57 UK gal/min, 5.49 US gal/min)
- First element 5.4 l/min (1.19 UK gal/min, 1.42 US gal/min)
- Second element 5.4 l/min (1.19 UK gal/min, 1.42 US gal/min)
- Third element 10 l/min (2.2 UK gal/min, 2.6 US gal/min)
Type MR200 Rotor
Displacement
199.8 cc/rev (12.19 in
3
/rev)
Services Operated:
- Spool 1 Tip
- Spool 2 2nd Speed
- Spool 3 Travel right
- Spool 4 Lift
- Spool 5 Travel left
P
T
12
3
45
