Section 3 - Maintenance
Routine Maintenance
Greasing
3-11 3-11
9803-9570-4
Greasing
Read and understand Lubricants - Health and Safety,
before greasing. You must grease the machine regularly to
keep it working efficiently. Regular greasing will also
lengthen the machine's working life. For the recommended
frequencies K
Service Schedules ( T 3-5).
Note: If working in extremely wet, muddy or dusty
conditions the fittings must be greased more often.
Note: The machine must always be greased after
pressure-washing or steam cleaning.
Greasing should be done with a grease gun. Normally, two
strokes of the gun should be enough. Stop greasing when
fresh grease appears at the joint. Use only JCB HP
Grease.
Before greasing, do the following:
1 Park the machine on firm, level ground, raise the skip
and stop the engine.
Skip Greasing Points
Fig 2.
Lift Arm Greasing Points
Fig 3.
