jcb Dumpster HTD5 User Manual

Section 1 - General Information
Machine Identification
Identifying Your Machine
1-3 1-3
9803/9570-4
Machine Identification
Identifying Your Machine
The machine has a data plate A attached to the chassis as
shown.
The serial (VIN) number of the machine is stamped on the
plate together with the machine weight, engine power and
year of manufacture.
Fig 1.
The machine serial number is also stamped on the chassis
in two places - on the top face of the tower arm B and on
the top face of the main chassis under the hydraulic tank
(not shown).
Fig 2.
Fig 3.
S
YEAR OF MANUF.
T
PIN Prod.Ident. No.
817/18435
ENGINE POWER kW @ RPM
E
I
F
VIN Vehicle Ident. No.
E
R
I
R
M
R
WEIGHT Kg
G
E
D
JCB COMPACT PRODUCTS LIMITED
HAREWOOD ESTATE, LEEK ROAD,
CHEADLE, STOKE ON TRENT,
UNITED KINGDOM, ST10 2JU.
