– 103 –
8-8-2. List of function settings
Abbreviation Function item
0 NOP No function
1 HS Needle up/down correction stitching
2 BHS Reverse-feed correction stitching
3 EBT Function for cancelling reverse-feed stitching (at end) once
4 TSW Thread trimmer function
5 FL Presser lifter function
6 OHS 1-stitch correction stitching
7 SEBT Function for cancelling reverse-feed stitching (at start) (at end)
8 LINH Function for prohibiting depress on the front part of pedal
9 TINH Thread trimmer output prohibition function
10 LSSW Low-speed command input
11 HSSW High-speed command input
12 USW Needle lifter function
13 BT Reverse-feed stitching switch input
14 SOFT Soft-start switch input
15 OSSW One-shot speed command switch input
16 BKOS Reverse-feed one-shot speed command switch input
17 SFSW Safety switch input
18 AUBT Automatic reverse-feed stitching cancellation/addition switch
19 CUNT Sewing counter input
20 OTSW One-touch change-over switch
21 ED Material-end sensor input
(1) List of input functions
Abbreviation Function item
0 NOP No function
1 TRM Thread trimmer output
2 NIP Thread presser output
3 FL Presser lifter output
4 BT Reverse-feed stitching output
5 SSTA Sewing machine stop-state output
6 COOL Needle cooler output
7 LSWO Rotation command output
(2) List of output functions
