– 17 –
[LU-2810, 2810-7, 2818-7]
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power off and ascertaining that the motor is at rest.
Thread the machine head following the order
as illustrated in the gure.
* Pass thread through the right side of
thread guide
.
LU-2810-7
LU-2818-7
LU-2810
3-6. Threading the machine head
❺
❷
❻
❸
❹
❼
❼
❻
❺
❹
❸
❾
❽
❶
1. Thread guide
is necessary to prevent the thread from slipping off the needle eyelet when per-
forming thread trimming at a position which is outside the material.
2. If thread tangling failure occurs when starting sewing from the material edge, the thread should be
removed from the location where it is clamped with the spring of thread guide
, or thread guide
should be changed with another one. The replacement thread guide is separately available.
Part number of replacement thread guide: 40084142
