SSG 500 M Series Hardware Installation and Configuration Guide
12 Front Panel
Port Descriptions
This section explains the purpose and function of the following components:
Built-in Gigabit Ethernet Ports
Console Port
AUX Port
Built-in Gigabit Ethernet Ports
Four built-in 10/100/1000 Gigabit Ethernet ports provide LAN connections to hubs,
switches, local servers, and workstations. You can also designate an Ethernet port
for management traffic.
When configuring one of these ports, you reference the interface name that
corresponds to the location of the port. From left to right on the front panel, the
interface names for the ports are ethernet0/0 through ethernet0/3.
Each port has two LEDs located on the top of the port. Figure 3 displays the location
of the LEDs on each Ethernet port, and Table 3 shows the name, function, color,
state, and description of the Ethernet port LEDs.
ALARM Red On steadily Critical alarm:
Failure of hardware component or software
module
Firewall attacks detected
Amber On steadily Major alarm:
Low memory (less than 10% remaining)
High CPU utilization (more than 90% in use)
Session full
Maximum number of VPN tunnels reached
HA status changed or redundant group member
not found
Off No alarms
HA Green On steadily Unit is the primary (master) device
Amber On steadily Unit is the secondary (backup) device
Off High availability not enabled
Name Color Status Description
