Juniper SSR130 Hardware Guide

Rear Panel of an SSR130
Figure 3 on page 12 shows the rear panel of an SSR130.
Figure 3: SSR130 Rear Panel
3—1— Power inputGround terminal
2—Fans
NOTE: The SSR130 does not support the following:
•
PoE power input
•
Redundant power adapter
Chassis Status LEDs
The SSR130 has three LEDs on the front panel to indicate the status.
Figure 4: Chassis LEDs
Table 2 on page 13 describes the chassis status LEDs on SSR130, their colors and states, and the status
that they indicate.
12
