Mount an SSR130 on a Two-Post Rack
If you need to mount an SSR130 on a two-post rack you must order the rack-mount kit (SSR100-RMK).
Before mounting an SSR130 on a two-post rack:
•
Verify that the site meets the requirements described in “SSR130 Site Guidelines and Requirements” on
page 20.
•
Place the rack in its permanent location, allowing adequate clearance for airflow and maintenance, and
secure it to the building structure.
•
Read General Safety Guidelines and Warnings, with particular attention to Chassis and Component Lifting
Guidelines.
Ensure that you have the following parts and tools available:
•
Separately oderable rack mount kit (SSR100-RMK)
•
2 Mounting Brackets
•
4 M5x7.0mm flat-head bracket screws
•
4 flat-head M6x16mm Phillips round head mounting screws
•
4 M6 Floating nut in cage, steel+zinc
•
4 M6 plastic washers
•
Phillips (+) screwdriver, number 2
NOTE: One person must be available to lift the SSR130 chassis while another secures the chassis
to the rack.
CAUTION: If you are mounting multiple units on a rack, mount the heaviest unit at
the bottom of the rack and mount the other units from the bottom of the rack to the
top in decreasing order of the weight of the units.
To mount the SSR130 on a two-post rack:
1. Remove the SSR130 from the shipping carton (see “Unpack an SSR130” on page 28).
2. Align the mounting brackets along the front of the appliance such that the holes in the mounting
brackets align with the holes on the side panels of the appliance. See Figure 7 on page 32.
31
