Bluetooth® DeviceBluetooth® Device
Presetting phone numbers
You can preset up to five phone numbers.
1 Display the phone control screen.
From the Home screen (page 3), touch as
follows:
2 Select which phone to use if two mobile
phones are connected.
Device Name 1
1
Device Name 2
2
1234XXXXXX
12 3
45 6
78 9
*
0/+ #
X
*
The currently active device is highlighted.
* Displays the <Connections SETUP> screen (page 10).
3 Select call history or phone book (1), and
then select a contact (
2) to preset.
Device Name 1
1
Device Name 2
2
Name 1
Name 1
1234XXXXXX
2345XXXXXX
Name 3
3456XXXXXX
Name 4
4567XXXXXX
Name 5
8901XXXXXX
A-Z
4 Select a preset number to store into.
Device Name 1
1
Device Name 2
2
1234XXXXXX
2345XXXXXX
3456XXXXXX
No preset
No preset
(Hold)
To delete the contact in the preset number: Touch
[ ] besides the contact on the preset list.
Bluetooth mobile phone settings
You can change various settings for using Bluetooth
devices on the <TEL SET-UP> screen.
1 Display the <TEL SET-UP> screen.
From the Home screen (page 3), touch as
follows:
Then, on the <Settings> screen, touch as follows:
[System] <Connections SETUP> : [Enter]
<TEL SET-UP> : [Enter].
TEL SET-UP
Auto Response
Auto Pairing
Auto Connect
Bluetooth HF/Audio
Front Only
ALL
ON OFF
ON OFF
ON OFF
On the <TEL SET-UP> screen, you can change and
confirm the following items.
32
ENGLISH
00KWM785DBWEN.indb3200KWM785DBWEN.indb32 2022/10/1715:112022/10/1715:11

Table of Contents

Question and Answer IconNeed help?

Do you have a question about the JVC KW-M785DBW and is the answer not in the manual?

JVC KW-M785DBW Specifications

General IconGeneral
DimmerYes
DIN size2 DIN
Impedance8 Ω
Output power200 W
Product colorBlack
Frequency range20 - 88000 Hz
Disc types supportedNo
Audio output channels- channels
Equalizer bands quantity8
Maximum power per channel50 W
Analog signal format systemNTSC, PAL
Signal-to-Noise Ratio (SNR)98.5 dB
Display typeLCD
Display diagonal6.8 \
Touchscreen typeCapacitive
Display resolution800 x 480 pixels
Illumination colorBlue, Green, Red
AM band range531 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsDAB+
Preset stations quantity20
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi frequency2.4 GHz
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
Line outputs (RCA)1
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Video formats supportedH.264, MKV, MPEG1, MPEG2, MPEG4, WMV
Hands-free callingKeep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e
Built-in processor-
Weight and Dimensions IconWeight and Dimensions
Depth75 mm
Width180 mm
Height100 mm
Weight1200 g
Installation compartment width182 mm
Installation compartment height111 mm
