# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
******************************
MECHANISM ASSEMBLY(VHS) <M3>
1 LP20821-009A MAIN DECK ASSY
3 LP30492-002B GUIDE POLE GUARD
4 NAH0001-001 FULL ERASE HEAD
5 LP40701-001A GUIDE POLE(SUPPLY)
6 QYTDST2608Z SCREW,FE HEAD
7 LP40637-002A TENSION STUD BASE ASSY
10 QYTDST2606Z SCREW
11 LP30409-002C UV CATCHER 2 (SUPPLY)
12 LP30409-002C UV CATCHER 2 (TAKE UP)
13 QYTPST2606Z SCREW,X2
15 LP30223-003C LOADING ARM GEAR SHAFT
16 QYTDST2606Z SCREW
18 LP30224-001B LOADING ARM GEAR(SUPPLY)
19 LP40099-001A TORSION ARM
20 LP40100-001A PIN
21 LP40101-006A POLE BASE ASSY(SUPPLY)
22 QYSPSTG2606Z SCREW
23 LP40103-002B LOADING ARM GEAR(TAKE UP)
24 LP40099-001A TORSION ARM
25 LP40100-002A PIN
26 LP40104-006A POLE BASE ASSY(TAKE UP)
27 QYSPSTG2606Z SCREW
31 LP20233-004B ROTARY ENCODER GUIDE
32 QYTPST2606Z SCREW
34 LP30226-004E CONTROL PLATE GUIDE
35 QYTPST2605Z SCREW
36 LP30249-003B TAKE UP LEVER
37 LP30003-006A TENSION SPRING
38 LP40119-002A TAKE UP HEAD
39 LP20234-004B LID GUIDE
40 QYTDST2606Z SCREW,X2
42 LP40105-003A PINCH ROLLER ARM ASSY
43 LP40753-001A PINCH ROLLER SHEET3
44 LP40148-002A TORSION SPRING
46 LP40149-001C PRESS LEVER ASSY
49 LP40106-007A GUIDE ARM ASSY
51 LP40134-002A TENSION SPRING
52 QAH0058-001 AC HEAD
53 LP30228-001C HEAD BASE
54 LP30004-013A COMPRESSION SPRING,X3
55 LP40236-001A COMPRESSION SPRING
57 LP40213-002B SPECIAL SCREW,X3
58 QYTDST2608Z SCREW,X2
59 QAR0023-001 LOADING MOTOR
60 PQ43546-1-2 MOTOR PULLEY
61 LP30230-003D MOTOR GUIDE
62 QYTPSP3003Z SCREW,X2
63 LP30005-003A BELT,LOADING MOTOR
64 LP20791-002D CONTROL CAM
65 PQM30017-24 SLIT WASHER
66 LP40120-001A WORM GEAR
67 LP40107-002A LINK LEVER ASSY
68 PQM30017-24 SLIT WASHER
69 LP10201-003G CONTROL PLATE
70 LP40379-001B CONTROL BRACKET(1)
71 QYTDSF2608M SCREW
72 LP40108-001A TENSION ARM ASSY
73 LP30003-010A TENSION SPRING
74 LP40109-003D TENSION BRAKE ASSY
75 PQ46302-1-3 ADJUST PIN
76 LP30232-002A TENSION ARM BEARING
78 LP40532-008B MAIN BRAKE ASSY (SUPPLY)
80 LP40111-011A MAIN BRAKE ASSY (TAKE UP)
81 LP30003-026A TENSION SPRING
82 LP40112-001F SUB BRAKE ASSY(TAKE UP)
83 LP40357-002A TENSION SPRING
84 LP40461-001A CAPSTAN BRAKE ASSY
85 QAR0087-005 CAPSTAN MOTOR
86 QYTDSF2606M SCREW,X3
87 LP30005-007A BELT,CAPSTAN MOTOR
88 LP40114-011B IDLER ARM ASSY
89 LP30016-001A SLIT WASHER
90 LP40593-003C CLUTCH UNIT 3
91 LP30002-097A SPACER,CAPSTAN MOTOR
92 PQM30017-47 SLIT WASHER
93 LP30696-002A CLUTCH GEAR 4
94 LP30697-003A COUPLING GEAR
95 LP40554-002A COMPRESSION SPRING
96 LP40442-001A DIRECT GEAR
97 LP30017-019A SPACER,C.GEAR4
99 LP40483-002A COMPRESSION SPRING
100 LP30016-001A SLIT WASHER,DIRECT GEAR
101 LP30016-001A SLIT WASHER,REEL DISK(SUPPLY)
102 LP40484-001J CHANGE LEVER ASSY
103 LP40512-002B COMPRESSION SPRING
104 LP30236-002C IDLER LEVER
105 LP20237-004A REEL DISK (SUPPLY)
106 LP20238-004A REEL DISK (TAKE UP)
107 LP30017-022A SPACER,X2
108 QSW0554-003 ROTARY ENCODER
109 QYTPST2620Z SCREW
110 LP30237-002B CASSETTE GEAR
111 LP30239-002G LIMIT GEAR(1)
112 LP30240-002G LIMIT GEAR(2)
113 LP40136-001E TORSION SPRING
114 LP30242-002B RELAY GEAR
115 LP30339-002F OPENER GUIDE
116 LP40545-001A TORSION SPRING
117 LP40214-001B C.H.BRACKET
118 PQM30017-47 SLIT WASHER,X2
119 LP30243-002A DRIVE GEAR
120 LP20240-001G DRIVE ARM
121 LP40137-001A TORSION SPRING
122 LP10081-002P SIDE HOLDER(L)
123 LP10082-002V SIDE HOLDER(R)
124 LP30255-006B LOCK LEVER(L)
127 LP30256-001H LOCK LEVER(R)
128 LP40168-003A TORSION SPRING(L)
129 LP40218-001B TORSION SPRING(R)
130 LP30257-001G CASSETTE HOLDER
132 LP30244-002G GUIDE RAIL
134 LP30245-002F REC SAFETY LEVER
135 LP30003-004A TENSION SPRING
137 LP20578-001C TOP GUIDE
138 LP30500-001C HOLD PLATE
139 LP40450-003A PAD,X2
140 LP30003-025B TENSION SPRING
141 LP30003-024A TENSION SPRING
142 LP40481-003A ROLLER CAM ASSY
143 LP30019-014A PAD,X2
151 LP20324-003B DOOR OPENER
To Next Page
