JVC SR-VS30U Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-20
D7016 SLR-342MC3F LE DIODE
R7001 QRE141J-471Y RESISTOR 470Ø,1/4W
R7002 QRE141J-471Y RESISTOR 470Ø,1/4W
R7003 QRE141J-471Y RESISTOR 470Ø,1/4W
R7004 QRE141J-471Y RESISTOR 470Ø,1/4W
R7006 QRE141J-103Y RESISTOR 10kØ,1/4W
R7007 QRE141J-103Y RESISTOR 10kØ,1/4W
R7008 QRE141J-103Y RESISTOR 10kØ,1/4W
R7013 QRE141J-103Y RESISTOR 10kØ,1/4W
R7014 QRE141J-0R0Y RESISTOR 0Ø,1/4W
R7015 QRE141J-0R0Y RESISTOR 0Ø,1/4W
R7020 QRE141J-103Y RESISTOR 10kØ,1/4W
R7021 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7022 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7023 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R7024 QRE141J-272Y RESISTOR 2.7kØ,1/4W
R7025 QRE141J-472Y RESISTOR 4.7kØ,1/4W
R7026 QRE141J-682Y RESISTOR 6.8kØ,1/4W
R7027 QRE141J-153Y RESISTOR 15kØ,1/4W
R7028 QRE141J-393Y RESISTOR 39kØ,1/4W
R7030 QRE141J-103Y RESISTOR 10kØ,1/4W
R7031 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7032 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7033 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R7034 QRE141J-272Y RESISTOR 2.7kØ,1/4W
R7035 QRE141J-472Y RESISTOR 4.7kØ,1/4W
R7036 QRE141J-682Y RESISTOR 6.8kØ,1/4W
R7037 QRE141J-153Y RESISTOR 15kØ,1/4W
R7038 QRE141J-393Y RESISTOR 39kØ,1/4W
R7040 QRE141J-103Y RESISTOR 10kØ,1/4W
R7041 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7042 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7051 QRE141J-331Y RESISTOR 330Ø,1/4W
R7052 QRE141J-331Y RESISTOR 330Ø,1/4W
R7053 QRE141J-331Y RESISTOR 330Ø,1/4W
R7054 QRE141J-331Y RESISTOR 330Ø,1/4W
R7055 QRE141J-331Y RESISTOR 330Ø,1/4W
R7056 QRE141J-331Y RESISTOR 330Ø,1/4W
R7057 QRE141J-331Y RESISTOR 330Ø,1/4W
R7058 QRE141J-331Y RESISTOR 330Ø,1/4W
R7191 QRE141J-750Y RESISTOR 75Ø,1/4W
R7192 QUY153-050Y IM BUS WIRE
R7193 QRE141J-750Y RESISTOR 75Ø,1/4W
R7194 QRE141J-750Y RESISTOR 75Ø,1/4W
B7001 QUY153-050Y IM BUS WIRE
C7001 QCFB1HZ-104 CAPACITOR 0.1µF,50V
C7007 QERF0JM-476 E CAPACITOR 47µF,6.3V
C7010 QCFB1HZ-104 CAPACITOR 0.1µF,50V
C7011 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C7019 QDVB1EZ-223Y CAPACITOR 0.022µF,25V
C7023 QERF1HM-106 E CAPACITOR 10µF,50V
C7192 QCBB1HK-681 CAPACITOR 680pF,50V
C7194 QCBB1HK-681 CAPACITOR 680pF,50V
C7196 QDYB1CM-103Y CAPACITOR 0.01µF,16V
L7001 QQL29BK-1R0Z COIL 1.0µH
L7002 QUY153-050Y IM BUS WIRE
L7191 QRE141J-101Y RESISTOR 100Ø,1/4W
L7192 QRE141J-101Y RESISTOR 100Ø,1/4W
L7193 QUY153-050Y IM BUS WIRE
L7194 QUY153-050Y IM BUS WIRE
S7004 QSW0456-002Z TACT SWITCH,REC
S7005 QSW0456-002Z TACT SWITCH,PAUSE
S7006 QSW0456-002Z TACT SWITCH,PLAY
S7007 QSW0456-002Z TACT SWITCH,STOP
S7008 QSW0456-001Z TACT SWITCH,I-O/R-SPD
S7009 QSW0456-001Z TACT SWITCH,ST/CANCEL
S7010 QSW0456-002Z TACT SWITCH,DV/HDD
S7011 QSW0456-002Z TACT SWITCH,VHS EJECT
S7012 QSW0456-002Z TACT SWITCH,EXP.T/MENU
S7013 QSW0456-002Z TACT SWITCH,VHS
S7015 QSW0456-001Z TACT SWITCH,RAE/SUMBNL
S7016 QSW0456-001Z TACT SWITCH,INS/R-LINK
S7017 QSW0456-001Z TACT SWITCH,A.DUB
S7021 QSW0456-002Z TACT SWITCH,DV>VHS/REW
S7022 QSW0456-002Z TACT SWITCH,DV<VHS/FF
S7023 QSW0456-002Z TACT SWITCH,DUB
DI7001 QLF0031-002 FL TUBE
HD1 PQ34949 FDP HOLDER(L),DI7001
HD2 PQ34950 FDP HOLDER(R),DI7001
HD3 PQM30038-2-2 LED HOLDER,D7009
HD4 PQM30038-2-2 LED HOLDER,D7010
HD5 PQM30038-2-2 LED HOLDER,D7011
HD6 PQM30038-2-2 LED HOLDER,D7012
HD7 PQM30038-2-2 LED HOLDER,D7013
HD8 PQM30038-2-2 LED HOLDER,D7014
HD9 PQM30038-2-2 LED HOLDER,D7015
HD10 PQM30038-2-2 LED HOLDER,D7016
FW7001 QUM023-12A4A4 P.R.WIRE,(1-3)POWER SW
FW7003 QUM024-08A4A4 P.R WIRE,(1-4)JOG
J7191 QNN0371-004 PIN JACK,FRONT V IN
J7192 QNN0371-003 PIN JACK,FRONT L IN
J7193 QNN0372-002 PIN JACK,FRONT R IN
J7194 QND0085-001 S JACK,FRONT S IN
J7195 PU60659 MINI JACK,PAUSE
CN7001 QGF1201C1-20 FPC CONNECTOR,(1-20)VHS MAIN
CN7191 QGF1201F1-10 FPC CONNECTOR,(1-10)VHS MAIN
******************************
DV MAIN BOARD ASSEMBLY <50>
PW1 LPA10165-05A DV MAIN BOARD ASSY
IC1001 MM1561JF IC
IC1002 MM1572FN IC
IC1003 MM1573AN IC
IC1004 MM1572KN IC
IC1005 S-80823ANNP-W IC
IC1501 MN103004KFG IC
or MN1030F04KHFFG IC
IC1502 TC7W14FK IC
IC1503 TC7W04FU IC(DIGITAL)
IC1504 25LC040-I/SN-X IC
IC2001 JCY0176 IC
IC2002 JCY0136 IC
IC2007 TLC2940IPW IC
IC3001 JCP8029 IC
IC3101 TC7SH04F IC(DIGITAL)
IC3102 TC7SH04F IC(DIGITAL)
IC3151 M62366GP IC
IC3501 NJM2538V IC
