JVC SR-VS30U Service Manual

5-19
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
C572 NDC21HJ-680X CAPACITOR 68pF,50V
C573 NDC21HJ-680X CAPACITOR 68pF,50V
C901 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C902 NCB21HK-103X CAPACITOR 0.01µF,50V
C903 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C904 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C905 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C906 NCB21HK-103X CAPACITOR 0.01µF,50V
C907 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C908 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C909 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C910 NCB21HK-272X CAPACITOR 0.0027µF,50V
L501 QQL29BJ-100Z COIL 10µH
L503 QQL29BJ-100Z COIL 10µH
L505 QUY153-050Y IM BUS WIRE
L901 QQL29BJ-4R7Z COIL 4.7µH
OT1 QYTDSF3008Z SCREW,X7
ET1 LP30918-001A EARTH PLATE
! TB1 LP10414-002B TERMINAL BOARD
J901 QND0084-001 S JACK,S IN
J902 QND0084-001 S JACK,S1 OUT
J903 QND0084-001 S JACK,S2 OUT
J904 QNN0364-003 PIN JACK,AV IN
J907 QNN0363-004 PIN JACK,A1 V1 IN
J910 QNN0363-004 PIN JACK,A2 V2 IN
J913 PU60659 MINI JACK,CB/BS R C
CN502 QGF1208F1-15 FPC CONNECTOR,(1-15)VHS MAIN
CN503 QGB2024J1-09S CONNECTOR,(1-9)VHS MAIN
CN504 QGB2024J1-10S CONNECTOR,(1-10)VHS MAIN
CN505 QGB2024J1-12S CONNECTOR,(1-12)VHS MAIN
CN506 QGB2024J1-11S CONNECTOR,(1-11)VHS MIAN
CN901 QGF1208F1-05 FPC CONNECTOR,(1-5)VHS MAIN
******************************
A/C HEAD BOARD ASSEMBLY <12>
PW1 LP10122-01A1 A/C HEAD BOARD ASSY
CN1 QGF1208F1-07 FPC CONNECTOR
******************************
DEMOD BOARD ASSEMBLY <14>
PW1 PB11076A DEMOD BOARD ASSY
IC1501 UPC1852AGT IC
or UPC1854AGT IC
R1501 QRE141J-102Y RESISTOR 1kØ,1/4W
R1502 QRE141J-334Y RESISTOR 330kØ,1/4W
R1503 QRE141J-124Y RESISTOR 120kØ,1/4W
R1504 QRE141J-302Y RESISTOR 3kØ,1/4W
R1505 QRE141J-512Y RESISTOR 5.1kØ,1/4W
R1506 QRE141J-333Y RESISTOR 33kØ,1/4W
R1507 QRE141J-333Y RESISTOR 33kØ,1/4W
R1508 QRE141J-392Y RESISTOR 3.9kØ,1/4W
R1509 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R1510 QRE141J-392Y RESISTOR 3.9kØ,1/4W
R1511 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R1517 QRE141J-123Y RESISTOR 12kØ,1/4W
C1501 QETN1CM-226 E CAPACITOR 22µF,16V
C1502 QETN1HM-104 E CAPACITOR 0.1µF,50V
C1503 QETN1HM-105 E CAPACITOR 1µF,50V
C1504 QETN1HM-475 E CAPACITOR 4.7µF,50V
C1505 QETN1HM-225 E CAPACITOR 2.2µF,50V
C1506 QETN1HM-104 E CAPACITOR 0.1µF,50V
C1507 QFV11HJ-473 F CAPACITOR 0.047µF,50V
C1508 QETN1HM-474 E CAPACITOR 0.47µF,50V
C1509 QETN1HM-104 E CAPACITOR 0.1µF,50V
C1510 QETN1HM-105 E CAPACITOR 1µF,50V
C1511 QETN1HM-105 E CAPACITOR 1µF,50V
C1512 QETN1HM-105 E CAPACITOR 1µF,50V
C1513 QETN1HM-335 E CAPACITOR 3.3µF,50V
C1514 QETN1HM-106 E CAPACITOR 10µF,50V
C1515 QETN1HM-105 E CAPACITOR 1µF,50V
C1516 QETN1HM-106 E CAPACITOR 10µF,50V
C1517 QETN1HM-106 E CAPACITOR 10µF,50V
C1518 QETN1HM-105 E CAPACITOR 1µF,50V
C1521 QETN1HM-106 E CAPACITOR 10µF,50V
BK1 LP40077-001A BRACKET(BOARD)
CN1501 QGG2502K1-09 HEADER PIN,(1-9)MAIN
******************************
POWER SW BOARD ASSEMBLY <27>
PW2 LPA10150-01A2 POWER SW BOARD ASSY
S7001 QSW0456-002Z TACT SWITCH,POWER
S7014 QSW0456-002Z TACT SWITCH,DV EJECT
******************************
SW/DISPLAY BOARD ASSEMBLY <28>
PW1 LPA10150-01B1 SW/DISPLAY BOARD ASSY
IC7001 M35500BFP IC
or M35500BGP IC
or M35500AGP IC
IC7002 GP1U281X IR DETECT UNIT
or PNA4652M00XB IR DETECT UNIT
D7002 RD9.1ES/B2/-T2 ZENER DIODE
or MTZJ9.1B ZENER DIODE
D7004 1SS133 DIODE
or 1SS270A DIODE
D7005 1SS133 DIODE
or 1SS270A DIODE
D7006 1SS133 DIODE
or 1SS270A DIODE
D7009 SLR-342DC3F LE DIODE
D7010 SLR-342MC3F LE DIODE
D7011 SLR-342VC3F LE DIODE
D7012 SLR-342DC3F LE DIODE
D7013 SLR-342MC3F LE DIODE
D7014 SLR-342VC3F LE DIODE
D7015 SLR-342MC3F LE DIODE
