JVC SR-VS30U Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-18
C1435 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1436 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1437 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1438 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1439 NCF21CZ-105X CAPACITOR 1µF,16V
C1440 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1441 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1442 NCF21CZ-105X CAPACITOR 1µF,16V
C1444 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1445 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1446 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C1447 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1448 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C1449 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1450 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1451 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C1452 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1453 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1454 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1455 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1459 NDC21HJ-470X CAPACITOR 47pF,50V
C1460 NDC21HJ-470X CAPACITOR 47pF,50V
C1461 NDC21HJ-470X CAPACITOR 47pF,50V
C1462 NDC21HJ-470X CAPACITOR 47pF,50V
C1463 QEKJ0JM-336 E CAPACITOR 33µF,6.3V
C1465 NDC21HJ-470X CAPACITOR 47pF,50V
C1466 NDC21HJ-470X CAPACITOR 47pF,50V
C1467 NDC21HJ-470X CAPACITOR 47pF,50V
C1468 NDC21HJ-101X CAPACITOR 100pF,50V
C1471 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1472 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1473 NCF21EZ-104X CAPACITOR 0.1µF,25V
L1401 QQL29BJ-100Z COIL 10µH
L1402 QQL071J-6R8Y COIL 6.8µH
L1403 QQL071J-6R8Y COIL 6.8µH
L1404 QQL071J-6R8Y COIL 6.8µH
L1405 QQL29BJ-100Z COIL 10µH
L1406 QQL071J-330Y COIL 33µH
L1407 QQL29BJ-100Z COIL 10µH
LC1401 QQR0521-007Z NOISE FILTER
LC1402 QQR0521-006Z NOISE FILTER
SD1 LP30706-001C SHIELD FRAME(S-VHS)
SD2 LP30684-001A SHIELD CASE(S-VHS)
CN1401 QGG2502K1-17 HEADER PIN,(1-17)MAIN
******************************
TERMINAL BOARD ASSEMBLY <06>
PW1 LPA10152-01C TERMINAL BOARD ASSY
IC501 JCP8018 IC
or JCP8028 IC
or JCP8028-01 IC
or JCP8038 IC
IC901 BA7623F IC
R503 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R516 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R517 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R525 QRE141J-125Y RESISTOR 1.2MØ,1/4W
R531 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R532 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R533 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R534 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R535 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R536 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R902 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R903 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R904 NRSA02J-680X MG RESISTOR 68Ø,1/10W
R905 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R906 NRSA02J-680X MG RESISTOR 68Ø,1/10W
R907 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R908 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R911 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R912 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R913 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R914 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R915 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R916 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R917 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R918 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R919 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R920 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R921 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R922 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B551 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B552 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B901 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B902 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C501 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C502 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C503 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C504 NCB21EK-104X CAPACITOR 0.1µF,25V
C506 NCB21HK-103X CAPACITOR 0.01µF,50V
C507 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C508 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C509 QEKJ1CM-106 E CAPACITOR 10µF,16V
C510 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C511 NCB21HK-103X CAPACITOR 0.01µF,50V
C512 NCB21HK-103X CAPACITOR 0.01µF,50V
C513 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C514 NCB21HK-103X CAPACITOR 0.01µF,50V
C515 NCB21HK-103X CAPACITOR 0.01µF,50V
C516 NCB21HK-103X CAPACITOR 0.01µF,50V
C518 NCB21EK-104X CAPACITOR 0.1µF,25V
C519 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C520 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C535 NCB21HK-103X CAPACITOR 0.01µF,50V
C551 QEKJ1HM-105 E CAPACITOR 1µF,50V
C553 NCB21HK-103X CAPACITOR 0.01µF,50V
C554 QEKJ1HM-105 E CAPACITOR 1µF,50V
C556 NCB21HK-103X CAPACITOR 0.01µF,50V
C557 QEKJ1HM-105 E CAPACITOR 1µF,50V
C559 NCB21HK-103X CAPACITOR 0.01µF,50V
C560 QEKJ1HM-105 E CAPACITOR 1µF,50V
C561 QEKJ1HM-105 E CAPACITOR 1µF,50V
C563 NCB21HK-103X CAPACITOR 0.01µF,50V
C568 NDC21HJ-680X CAPACITOR 68pF,50V
C569 NDC21HJ-680X CAPACITOR 68pF,50V
C570 NDC21HJ-680X CAPACITOR 68pF,50V
C571 NDC21HJ-680X CAPACITOR 68pF,50V
