5-7
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
******************************
MECHANISM ASSEMBLY(DV) <M4>
401 PRD10428A MAIN DECK ASSY
402 LY30358-001A DRUM BASE DECK
403 YQ43893 MINI SCREW,X27
404 LY30343-001A WORM WHEEL 2
405 LY40237-001C ENT.GUIDE BASE ASSY
407 LY30340-004A MOTOR BRACKET ASSY
409 LY41190-003A ROTARY ENCODER ASSY
411 YQ31873B-31 GUIDE RAIL ASSY(SUPPLY)
414 LY20097-001C GUIDE RAIL ASSY(TAKE UP)
417 QAR0012-002 CAPSTAN MOTOR
418 LY30002-003A COMPRESSION SPRING
419 LY41390-001A ADJUST NUT
420 LY30345-001A MIDDELE CATCHER ASSY
422 LY40223-001A ARM GEAR 1 ASSY
423 LY40224-001A COLLAR
424 LY40235-002B CENTERRING ARM ASSY
425 LY10060-003A MAIN CAM
426 YQ44246 SLIT WASHER,X7
427 LY40279-001A ARM GEAR 2 ASSY
428 LY40228-001A CLUCH LOCK LEVER ASSY
429 LY20102-001A SUB CAM
431 LY30347-001A CHARGE ARM ASSY
432 YQ44560-1-2 CONNECT GEAR 2,X2
434 LY40236-001A TENSION CONTROL ARM ASSY
435 LY40233-001A BRAKE CONTROL ARM ASSY
437 LY40242-001C BASE PLATE ASSY
439 YQ43931A REEL DRIVE PULLEY ASSY
442 LY40239-003A CENTER GEAR ASSY
443 LY40241-001A TIMING BELT
444 LY40246-001A CLUTCH LOCK GEAR (1)
445 LY30002-009A COMPRESSION SPRING
446 LY40247-001A CLUTCH LOCK GEAR (2)
447 YQ43933-2 WASHER
448 LY40248-001A PUSH PLATE
450 PRD31443B SUB DECK ASSY(G)
450A LY20108-001B PRISM
450B YQ43893 MINI SCREW
452 LY20109-001B CONTROL PLATE
453 LY40257-001A SUB BRAKE ASSY
455 LY40259-003A MAIN BRAKE(T) ASSY
456 LY40260-003A MAIN BRAKE(S) ASSY
457 LY40255-003A REEL DISK ASSY
458 LY41245-001B TENSION ARM SUB ASSY
459 LY41243-001A TORSION SPRING
460 LY41246-003B BAND ARM PLATE SUB ASSY
461 PRD45316 SLIT WASHER
462 YQ43893-7 MINI SCREW
463 LY30370-002C SWING ARM ASSY
464 LY30380-001E EXIT GUIDE ARM ASSY
466 LY30374-001B PINCH ROLLER ARM ASSY
468 LY40280-003A REEL COVER ASSY
470 YDV2100A DRUM ASSY
471 YQ43893 MINI SCREW,X3
475 LL30228-1A-H DV MECHA UNIT
476 LY30428-005A CASSETTE HOUSING ASSY
477 QYTDSP2004Z SCREW,X2
478 PRD45370 ASSIST GUIDE
479 YQ43893 MINI SCREW
480 LL30210-001A-H BRACKET(MDA)
481 QYSDSP2002N SCREW,X2
482 LK2119A0A-H2 DV MDA BOARD ASSY
483 QYSDST2605Z SCREW,X2
