JVC SR-VS30U Service Manual

5-25
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
C4033 NCB31CK-104X CAPACITOR 0.1µF,16V
C4034 NDC31HJ-102X CAPACITOR 0.001µF,50V
C4035 NCB31CK-104X CAPACITOR 0.1µF,16V
C4036 NCB31CK-104X CAPACITOR 0.1µF,16V
C4038 NCB20JM-475X CAPACITOR 4.7µF,6.3V
C4039 NCB31CK-104X CAPACITOR 0.1µF,16V
C4040 NCB31CK-104X CAPACITOR 0.1µF,16V
C4041 NCB20JM-475X CAPACITOR 4.7µF,6.3V
C4046 NCB31CK-104X CAPACITOR 0.1µF,16V
C4047 NCB31CK-104X CAPACITOR 0.1µF,16V
L1001 NQL144K-100X COIL 10µH
L1002 NQL17CM-390X COIL 39µH
L1003 NQL17CM-390X COIL 39µH
L1004 NQL17CM-390X COIL 39µH
L1501 NQL144K-100X COIL 10µH
L1502 NQL144K-100X COIL 10µH
L2001 NQL144K-100X COIL 10µH
L2002 NQL144K-100X COIL 10µH
L2003 NQL144K-100X COIL 10µH
L2004 NQL144K-100X COIL 10µH
L2005 NQL144K-100X COIL 10µH
L2006 NQL144K-100X COIL 10µH
L2007 NQL144K-100X COIL 10µH
L2009 NQL024J-2R2X COIL 2.2µH
L2010 NQL024J-100X COIL 10µH
L2011 NQL024J-120X COIL 12µH
L2015 NQR0337-001X COIL
L3001 NQL144K-100X COIL 10µH
L3021 NQL144K-100X COIL 10µH
L3022 NQL144K-100X COIL 10µH
L3101 NQL144K-100X COIL 10µH
L3103 NQL144K-100X COIL 10µH
L3104 NQL144K-100X COIL 10µH
L3111 NQL024J-150X COIL 15µH
L3112 NQL024J-150X COIL 15µH
L3131 NQL024J-150X COIL 15µH
L3132 NQL024J-150X COIL 15µH
L3151 NQL144K-100X COIL 10µH
L3521 NQL144K-100X COIL 10µH
L3522 NQL144K-100X COIL 10µH
L3531 NQL024J-120X COIL 12µH
L3532 NQL024J-270X COIL 27µH
L3533 NQL024J-120X COIL 12µH
L3534 NQL024J-270X COIL 27µH
L3701 NQL144K-100X COIL 10µH
L3702 NQL144K-100X COIL 10µH
L4001 NQL144K-100X COIL 10µH
L4002 NQL144K-100X COIL 10µH
L4003 NQL144K-100X COIL 10µH
L4005 NQL144K-100X COIL 10µH
LC1002 PELN1148-223X NOISE FILTER
LC1003 PELN1148-223X NOISE FILTER
LC1004 PELN1148-223X NOISE FILTER
LC3101 PELN0969-04Y NOISE FILTER
X2001 NAX0141-001X CRYSTAL RESONATOR
X2003 NAX0206-001X CRYSTAL RESONATOR
X3101 NAX0218-001X CRYSTAL RESONATOR
K1001 NQR0129-002X FERRATE BEADS
K2001 NQR0129-002X FERRATE BEADS
K3101 NQR0129-002X FERRATE BEADS
K4001 NQR0129-002X FERRATE BEADS
SD1 LP30467-001A SHIELD COVER
ET1 QNZ0136-001Z EARTH TERMINAL
J2001 QNZ0097-001 D CONNECTOR,DV IN/OUT
CN1001 QGF1211F1-08W FPC CONNECTOR,(1-8)SW REG
CN1501 QGF0503C1-20X FFC/FPC CONNECTOR,(1-20)MDA
CN1502 QGF0505F2-15X FPC CONNECTOR,(1-15)DV MECHA
CN1503 QGF1211F1-04W FPC CONNECTOR,(1-4)VHS MAIN
CN2001 QGB0801L1-26X CONNECTOR,(1-26)JIG
CN3501 QGF1224F1-14X FFC/FPC CONNECTOR,(1-14)VHS MAIN
CN3701 QGF1016F2-08W FFC/FPC CONNECTOR,(1-8)VHS MAIN
CN4001 QGF0503C1-08X
FFC/FPC CONNECTOR,(1-8)DV PRE/REC
******************************
LOADING MOTOR BOARD ASSEMBLY <55>
PW2 LP10122-01A2 LOADING MOTOR BOARD ASSY
CN1 QGB2533K1-02 CONNECTOR
******************************
JOG BOARD ASSEMBLY <85>
PW3 LPA10150-01A3 JOG BOARD ASSY
UN7001 QSW0905-001 ROTARY ENCODER
(VP)-V14SD1
