5.5 ELECTRICAL PARTS LIST
******************************
SW REGULATOR BOARD ASSEMBLY <01>
PW1 LPA10153-02A SW REG BOARD ASSY
IC5201 L5431 IC
or MM1431AT IC
or UTCTL431 IC
IC5321 PQ15RW11 IC
Q5101 2SK2043-CB14 FE TRANSISTOR
or 2SK2043 FE TRANSISTOR
Q5102 2SD2144S/UV/-T TRANSISTOR
Q5321 2SC5739/QP/ TRANSISTOR
Q5322 2SD1819A/RS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
or 2SC4081/RS/-X TRANSISTOR
Q5323 2SA933AS/RS/-T TRANSISTOR
or 2SA1267/YG/-T TRANSISTOR
Q5324 DTC114EU DIGI TRANSISTOR
or PDTC114EU DIGI TRANSISTOR
or RN1302 DIGI TRANSISTOR
or UN5211 DIGI TRANSISTOR
Q5326 2SD1858/QR/-T TRANSISTOR
Q5327 2SD1819A/RS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
or 2SC4081/RS/-X TRANSISTOR
Q5328 2SD1302/ST/-T TRANSISTOR
or 2SD1450/ST/-T TRANSISTOR
Q5329 DTA114EU DIGI TRANSISTOR
or PDTA114EU DIGI TRANSISTOR
or RN2302 TRANSISTOR
or UN5111 DIGI TRANSISTOR
Q5331 2SB1068/KU/-T TRANSISTOR
Q5332 DTC114EU DIGI TRANSISTOR
or PDTC114EU DIGI TRANSISTOR
or RN1302 DIGI TRANSISTOR
or UN5211 DIGI TRANSISTOR
Q5335 2SA1576A/RS/-X TRANSISTOR
Q5339 2SD2144S/UV/-T TRANSISTOR
Q5340 DTA114EU DIGI TRANSISTOR
or PDTA114EU DIGI TRANSISTOR
or RN2302 TRANSISTOR
or UN5111 DIGI TRANSISTOR
Q5341 DTC114EU DIGI TRANSISTOR
or PDTC114EU DIGI TRANSISTOR
or RN1302 DIGI TRANSISTOR
or UN5211 DIGI TRANSISTOR
D5002 S1WB/A/60-4102 BRIDGE DIODE
or S1WB(A)60F4072X BRIDGE DIODE
or S1WB/A/60-X BRIDGE DIODE
D5101 AU01 DIODE
or 10ELS4 FR DIODE
D5102 AU01Z FR DIODE
or 10ELS4 FR DIODE
D5103 1SS133 DIODE
or 1SS270A DIODE
D5201 AU01Z FR DIODE
or 10ELS2 FR DIODE
D5202 MTZJ15C ZENER DIODE
or RD15ES/B3/-T2 ZENER DIODE
D5203 FMB-24 SB DIODE
or FSQ05A04B SB DIODE
or SB640FCT SB DIODE
or SF5SC4 SB DIODE
or YG801C04 SB DIODE
D5205 10ELS2 FR DIODE
or AU01Z FR DIODE
D5206 10ELS2 FR DIODE
or AU01Z FR DIODE
D5208 ERA18-02-T2 FR DIODE
or PG104RS FR DIODE
or 1SR153-400-T2 FR DIODE
or 10ELS2 FR DIODE
D5209 AU01Z FR DIODE
or ERA18-02-T2 FR DIODE
or PG104RS FR DIODE
or 1SR153-400-T2 FR DIODE
or 10ELS2 FR DIODE
D5210 AU01Z FR DIODE
or ERA18-02-T2 FR DIODE
or PG104RS FR DIODE
or 1SR153-400-T2 FR DIODE
or 10ELS2 FR DIODE
D5212 1SS133 DIODE
or 1SS270A DIODE
D5213 MTZJ27C ZENER DIODE
or RD27ES/B3/-T2 ZENER DIODE
D5214 MTZJ7.5A ZENER DIODE
or RD7.5ES/B1/-T2 ZENER DIODE
D5323 11ES2 DIODE
or ERA15-02-T2 DIODE
or 1A3G DIODE
D5325 RD5.1JS/B2/-T2 ZENER DIODE
or MA4051N/M/-T2 ZENER DIODE
D5326 1SS133 DIODE
or 1SS270A DIODE
D5327 RD5.1JS/B2/-T2 ZENER DIODE
or MA4051N/M/-T2 ZENER DIODE
D5328 1SS133 DIODE
or 1SS270A DIODE
D5337 11ES2 DIODE
or ERA15-02-T2 DIODE
or 1A3G DIODE
D5338 11ES2 DIODE
or ERA15-02-T2 DIODE
or 1A3G DIODE
D5339 1SS133 DIODE
or 1SS270A DIODE
D5340 1SS133 DIODE
or 1SS270A DIODE
!
R5001 QRZ9046-475Z RESISTOR 4.7MØ,1/2W
R5101 QRE141J-224Y RESISTOR 220kØ,1/4W
R5102 QRE141J-224Y RESISTOR 220kØ,1/4W
R5103 QRE141J-683Y RESISTOR 68kØ,1/4W
R5104 QRG02GJ-683 OMF RESISTOR 68kØ,2W
R5106 QRT01DJ-R39X MF RESISTOR 0.39Ø,1W
R5107 QRE121J-331Y RESISTOR 330Ø,1/2W
R5108 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R5109 QRE141J-681Y RESISTOR 680Ø,1/4W
R5110 NRSA02J-224X MG RESISTOR 220kØ,1/10W
R5201 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5202 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
