KEEWAY ARN150 User Manual

15
3 ．
．．
． E N G I N E A N D T R A N S I M I S S I O N S Y S T E M ( A ．
．．
． S P E C I A L T O R Q U E )
The following table liss torques of some locking accessories/fixers, which you can refer to in assembly.
NO.
NA ME QTY TORQUE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Tapping screw for fan snail cover assy.
Lucknut for fan snail cover assy.
Tapping screw for up and down guide air cover
Lucknut for up and down guide air cover
Tapping screw and nut for ventilating air chamber of cylinder head
covr
Locknut for cylinder head cover
Locknut for double head blot on cam fixing
holder
Locknut for atmolysis chain pulling rod
Lucknut for atmolysis chain adjustor
Lucknut for cylinder head
Locknut for cylinder observing oil read
Spark plug
Double head bolt for cylinder head inlet port
Double head bolt ofr cylinder head exhaust port
Lucknut for carburetor joint
Lucknut for cooling impeller of fan
Locknut for flywheel
Locknut for magnet stator coil
Locknut for magnet motor trigger
Locknut for right crankcase cover
Oil filter cover cap
Locknut for oil pump seperating board
Locknut for oil pump sprocket
Locknut for oil pump
Locknut for oil pump cover
Locknut for super-clutch
Locknut for super clutch outside
Locknut for right crankcase
Double head bolt for left and right crankcase
Fixing bolt for motro
Locknut for left crankcase cover and line coil
Tapping screw for ventilating guide board of left
crankcase cover
Locknut for driver disc
Locknut for driven disc
Locknut for driven disc clutch
Locknut for press-board of kick starter
Locknut for transmission case cover
Locknut for flowing oil hole of transmission case
Locknut for flowing oil hole of left crank.
Locknut for position shaft of left crank
2
2
3
1
3
4
4
1
2
2
1
1
2
2
2
4
1
2
2
9
1
2
1
2
1
1
3
2
4
2
11
4
1
1
1
1
5
2
1
1
1-3N••M
10-12N•M
1-3N••M
10-12N•M
1-3N••M
10-12N•M
22-25N•M
10-12N•M
10-12N•M
10-12N•M
10-12N•M
10-15 N•M
10-12N•M
10-12N•
M
10-12N•M
10-12N•M
45-55N•M
6-8N•M
10-12N•M
10-12N•M
55-60N•M
10-12N•M
8-10N•M
10-12N•M
1-3N••M
35-40N•M
10-12N•M
10-12N•M
22-25N•M
10-12N•M
10-12N•M
3-6N•M
45-55N•M
45-55N•M
55-60N•M
10-12N•M
10-12N•M
22-25N•M
40-45N•M
22-25N•M
