KEEWAY ARN150 User Manual

39
G ．
．．
． VA LV E C L E R A N C E S E T U P
Engine is in cooling state.
1、 Remove cylinder head cover；
2、 Remove pastern cap of fan whorl shell.；
3、 Keep “T” mark on flywheel the same line with the mark on righ crankcase cover；
4、 Ensure timing reticle of cam sprocket in the same line with joint surface of cylinder head cover.；
5、 Inspect the clearance of inlet valve and exhaust valve, inlet valve：0.03~0.05mm，exhaust valve：
0.05~0.06mm，if clearance is not at the range of specified volume, adjust rocker adjusting screw until the
clearance reaches its specified range.
