C a r b u r e t o r r e m o v a l a n d i n s t a l l a t i o n
Removal：
：：
：
1. Remove rear seat of motorcycle;
2. Postion fuel switch on “ OFF” position；
3. Pull out inlet oil paste tube with jaw；
4. loose clamp ring between carburetor and air cleaner；
5. Pull out the stopper at the tail of discharging oil paste tube, spill fule in floater chamber into another
box.；
6. Loose the screw for jointing carburetor and engine and take out carburetor；
7. Pull out high coil cap;
8. Pull out electric condensing valve joint;
9. Loose the screw for jointing carburetor and engine and remove carburetor;
10. Loose throttle cable.
Installation：
：：
：
The installation sequence is essentially the reverse of removal.
Notice：
：：
：
1、 Confirm electric condensing valve wire is connected correctly;
2、 Confirm carburetor is intalled correctly and no oil leaking out.
CARBURETOR ASSY.
STEPS FOR REMOVAL：
：：
：
1、 Remove 4 screws, take out stopper spring and stopper assy;
2、 Unscrew oil needle compaction cap, take out oil needle and oil needle spring;
3、 Unscrew misture ratio adjusting screw, spring, gasket and seal ring;
4、 Unscrew idle adjusting screw and screw；
5、 Remove electric condensing valve assy.；
6、 Remove choke valve assy.；
7、 Remvoe the 4 screws on under cover;
8、 Remove floater pin, floater and needle valve in turn；
9、 Remove main jet, foam tube and main nozzle in turn；
10、Unscrew idle jet；
11、clean various parts with gasoline, and then blow them with high pressure pneumatic gun.
Notice：
：：
：
1、 In the process of removing other accessories in floater chamber, first of all remove floater and needle valve
to ensure floater is not damaged；
2、 To preserve main nozzle, remove it from one side of stopper hole.
