Page #84 background image
84
Driven wheel disc sliding bearing is damaged Something is wrong with speedometer
Brake is soft
-The level of braking liquid is too low
-There is foam for Disc braking system
-Disc braking oil leaks out
-Disc braking caliper piston seal ring is aging.
-Stopper husk bowl is aging
-Braking shoe/braking disa is abraded
-Stopper/oil stopper is abraded
b It feels hard for brake/The tension of Disc brake level si slow
-Brake oil path is blocked
-Caliper cannt move normally
-Brake disc is distorted
-The tension spring of handle level is damaged
Rear wheel/rear brake/rear shock absorber
Rear wheel jumps/swings
-Rear wheel bearing is damaged
-Tire is bad
-Rim is distorted
-Rear wheel bearing is loose
-Rear wheel axes nut is loose
-Rear swing arm bush is abraded
-Chain adjuster is not adjusted correctly-
It is toward on side or it is not straightforward
-Rear wheel axes is distorted
-Chain adjuster is not adjusted equally
-Rear swing arm is distorted
Brake capability is bad
-Rear brake is not adjusted correctly
-Brake shoe is abraded
-There is oil dirty on brake shoe
-Braking cam is abraded
-Braking hub is abrade
-Braking rocker arm spline meshs improperly
-Touching position of Braking shoe and camshaft is abraded.
