b . I M P O R TA N T PA R T S
The following is detail information of vital position pin, O-ring, bearing, pin shaft and gasket of
ENGINE/UNDERPAN:
POSITION PIN-14NOS.
S.NO.
Size (mm) Qty. Description Location
1 10Фx16 2
Camshaft fixing seat and
cylinder head
Engine
2 10Фx16 2
Cylinder head and cylinder head
Engine
3 10Фx16 2 Crankcase and cylinder body Engine
4 10Фx16 2
Left and right crankcase
Engine
5 8Фx14 2 Left crankcase and gearbox Engine
6 10Фx16 2 Left crankcase and left cover Engine
7 8Фx14 2
Rignt crankcase and right
cover
Engine
O-ring-7NOS.
S.NO.
Size (mm) Qty. Description Location
1 9Фx1.6 2 Inlet and exhast valve pipe Engine
2 13.7Фx1.5 1 Atmolysis chain pulling lever Engine
3 9.5Фx1.5 1 Atmolysis chain adjustor Engine
4 18Фx3 1 Oil gauge Engine
5 30Фx3 1 Filter spring cap Engine
6 26502470 1 Starting moto Engine
Oil seal- 4NOS.
S.NO.
Size (mm) Qty. Description Location
1 27x42x7 1
Output shaft---gearbox cover
Engine
2 20x32x6 1
Output shaft—left crankcase
Engine
3 19.8x30x7 1
Crank—left crankcase
Engine
4 19.8x30x7 1
Crank—right cover
Engine
