Keithley 2260B-80-13 User Manual

CONFIGURATION
95
Steps
1. Press the Function key. The
function key will light up.
2. The display will show F-01
on the top and the
configuration setting for
F-01 on the bottom.
3. Rotate the Voltage knob to change
the F setting.
Voltage
Range
F-00~ F-61, F-88~F-89
4. Use the Current knob to set the
parameter for the chosen F setting.
Current
5. Press the Voltage knob to save the
configuration setting. ConF will be
displayed when successful.
Exit
Press the Function key again to exit
the configuration settings. The
function key light will turn off.
Voltage

Keithley 2260B-80-13 Specifications

General

Output Voltage Range	0 to 80 V
Output Current Range	0 to 13 A
Power Rating	1040 W
Temperature Coefficient	100 ppm/°C
Voltage Programming Accuracy	0.03% + 10 mV
Load Regulation	0.01% + 2 mV
Line Regulation	0.01% + 2 mV
Interface	USB, GPIB
Operating Temperature Range	0 to 40 °C
Storage Temperature Range	-40 to 70 °C
