Keithley 2260B-80-13 User Manual

2260B Series User Manual
96
Setting Power On Configuration Settings
Background
The Power On configuration settings can only
be changed during power up to prevent the
configuration settings being inadvertently
changed.
 Ensure the load is not connected.
 Ensure the power supply is off.
Steps
1. Hold the Function key while
turning the power on.
2. The display will show F-90 on the
top and the configuration setting
for F-90 on the bottom.
3. Rotate the Voltage knob to change
the F setting.
Voltage
Range
F-90~ F-95
4. Use the Current knob to set the
parameter for the chosen F setting.
Current

Keithley 2260B-80-13 Specifications

General

Output Voltage Range	0 to 80 V
Output Current Range	0 to 13 A
Power Rating	1040 W
Temperature Coefficient	100 ppm/°C
Voltage Programming Accuracy	0.03% + 10 mV
Load Regulation	0.01% + 2 mV
Line Regulation	0.01% + 2 mV
Interface	USB, GPIB
Operating Temperature Range	0 to 40 °C
Storage Temperature Range	-40 to 70 °C
